Switch and Sensor Locations

Center Slitter
Left Sensor
Left Margin
Slitter Sensor
20
DocuCutter 545
The DocuCutter DC-545 contains a series of Switches
and Sensors to determine paper position. The locations of
the Slitter Sensors within the DocuCutter DC-545 are
shown in Figure 11.
Option 1
Slitter Sensor
Figure 11. Slitter Sensor Locations
DocuCutter 545 Training Guide
Center Slitter
Right Sensor
Right Margin
Slitter Sensor
