DocuCutter 545
The remaining Switches and Sensors are shown below in
Figure 12.
Power Switch
Rear Cover Switch
Creaser Sensor
Front Cover Switch
Tray Switch
Door Switch
Figure 12. Switches and Sensors
© 2002, Duplo USA Corporation
DocuCutter 545 Training Guide
21
