DocuCutter 545
Creasing Position Detection
The preset job data indicates where the paper requires a
crease. When the lead edge of the paper triggers PPS3,
the microprocessor calculates the distance the paper
travels via the Stepper Motor control pulses. When the
desired distance is reached, the Creaser Drive Motor is
activated and the paper is creased.
30
DocuCutter 545 Training Guide
© 2002, Duplo USA Corporation
