The Control Panel
14
DocuCutter 545
The Control Panel on the DocuCutter DC-545 performs
the following functions:
•
Displays operation and machine status during
normal operation
•
Indicates when problems with the machine have
occurred
•
Allows for operator /service input to assist in jam
clearance
•
Provides service personnel with a method of
accessing the Service Mode Diagnostic Tools
The location of the Control Panel on the DocuCutter DC-
545 is shown in Figure 7.
Figure 7. Control Panel Location
DocuCutter 545 Training Guide
© 2002, Duplo USA Corporation
