Paper Handling
22
DocuCutter 545
Throughout the following paragraphs, you will be reading
about Slitters, a Cutter, and a Creaser. These
components are used in various combinations to finish
documents in the DocuCutter DC-545. Figure 13 is
provided below to help you understand the paper handling
terms associated with the DocuCutter DC-545.
You should note that, by definition, a cut or a crease is
perpendicular to the direction of paper feed, while a slit
is parallel to the paper feed direction.
PAPER FEEDING DIRECTION
Cut
REG Mark
(Optional)
Bar Code
(Optional)
Figure 13. Paper Handling Terms
DocuCutter 545 Training Guide
Slit
Crease
© 2002, Duplo USA Corporation
