DocuCutter 545
Note: If the CCD cannot scan the horizontal line within
50mm of feeding, "E4 - REG MARK ERROR" will be
displayed.
15. After the horizontal component of the REG Mark is
scanned, any required error correction is
calculated. Horizontal registration correction is
performed during the cutting and creasing
processes.
16. The document processing begins.
