Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11 (Optional)
CN12
CN14
CN15
CN16
CN17
ATX1
BAT1
SATA1
SCN1
SCN2
SDIMM1
12
Processor Family 3.5" Board
Description
Front Panel Connector
Fan Connector
Inverter Connector
LVDS Connector
SATA Power Connector
COM1 Wafer Connector
Audio Connector
USB 2.0 Wafer Port 5 and 6
Digital I/O Connector
SMBus Connector
Power Connector
Ethernet Port 1 and 2
USB 3.0 Port 3 and 4
USB 3.0 Port 1 & USB 2.0 Port 3 and 4
HDMI Connector
VGA Connector
ATX Power Connector
CMOS Battery Connector
SATA Port
Full-size PCI-Express Mini Card Connector
ZIO Expansion Connector
DDR4 SO-DIMM Connector
Board and Pin Assignments
