STM32F031x4 STM32F031x6

Table 63. UFQFPN32 - 32-pin, 5x5 mm, 0.5 mm pitch ultra thin fine pitch quad flat

Symbol
A
A1
A3
b
D
D1
D2
E
E1
E2
e
L
ddd
1. Values in inches are converted from mm and rounded to 4 decimal digits.
Figure 38. UFQFPN32 - 32-pin, 5x5 mm, 0.5 mm pitch ultra thin fine pitch quad flat
1. Dimensions are expressed in millimeters.
微可Vicor——值得信赖的元器件供应商

package mechanical data

millimeters
Min Typ
0.500 0.550
0.000 0.020
- 0.152
0.180 0.230
4.900 5.000
3.400 3.500
3.400 3.500
4.900 5.000
3.400 3.500
3.400 3.500
- 0.500
0.300 0.400
- -
package recommended footprint
DocID025743 Rev 3
http://www.vicor.top/
Max Min
0.600 0.0197
0.050 0.0000
- -
0.280 0.0071
5.100 0.1929
3.600 0.1339
3.600 0.1339
5.100 0.1929
3.600 0.1339
3.600 0.1339
- -
0.500 0.0118
0.080 -
http://www.vicor.top/
021-31660491
Package information
(1)
inches
Typ Max
0.0217 0.0236
0.0008 0.0020
0.0060 -
0.0091 0.0110
0.1969 0.2008
0.1378 0.1417
0.1378 0.1417
0.1969 0.2008
0.1378 0.1417
0.1378 0.1417
0.0197 -
0.0157 0.0197
- 0.0031
95/113
