In LACP mode, each pair of ports forms a logical channel between the controller and the
network, allowing for higher throughput. If one port fails, the other port provides a failover
connection. LACP mode requires version 1.7 or later of the StorageGRID Webscale Appliance
Installer.
• Aggregate Port Configuration – Starting with version 1.7 of the StorageGRID Webscale
Appliance Installer, you can specify that all four ports be grouped in a single LACP bond,
allowing all ports to be used for Grid network and Client network traffic. Aggregate Port
Configuration significantly increases the throughout for each network and provides additional
failover paths. When using Aggregate Port Configuration, you must specify a unique VLAN ID
for each network. This VLAN ID will be added to each network packet to ensure that network
traffic is routed to the correct network.
For more information on configuring these ports, see the instructions for cabling the appliance and
StorageGRID Webscale Software Installation Guide .
the appropriate
Related tasks

Gathering data for deploying StorageGRID Webscale appliance

Cabling the appliance
Related information
StorageGRID Webscale 10.4 Software Installation Guide for VMware Deployments
StorageGRID Webscale 10.4 Software Installation Guide for OpenStack Deployments
StorageGRID Webscale 10.4 Software Installation Guide for Red Hat Enterprise Linux
Deployments
Gathering data for deploying StorageGRID Webscale
appliance
Before deploying the StorageGRID Webscale appliance, you must gather information about Ethernet
switch ports and IP addresses.
About this task
Refer to StorageGRID Webscale appliance connections
to collect the information from your administrator.
Information needed
Specify the Ethernet switch port you will
connect to management port 1 on the E2700
controller (used to access the management
network for SANtricity Storage Manager)
Specify the Ethernet switch port you will
connect to management port 1 on the E5600SG
controller (used to access the Admin network
for StorageGRID Webscale)
on page 23
Planning your deployment | 17
on page 17
on page 15, and use the following worksheet
Your value
Switch port for management port 1 on E2700
controller:
Switch port for management port 1 on
E5600SG controller:
