R
Virtex-II Pro Prototype Platform

Package Contents

•
•
•
•
•
•
•

CD-ROM Contents

•
•
•
•
•
•

Introduction

Virtex-II Pro Prototype Platforms are prototype and demonstration boards that allow
designers to investigate and experiment with the features of Virtex-II Pro series FPGAs.
This document describes the features and operation of the boards, including how to
configure chains of FPGAs and serial PROMs. Prototype Platforms are intended strictly for
evaluating the functionality of Virtex-II Pro features and are not intended for A/C
characterization or high-speed I/O evaluation.
Virtex-II Pro Prototype Platform User Guide
UG027 / PN 0402044 (v1.6) October 25, 2002
Xilinx Virtex-II Pro™ Prototype Platform board
User guide
Device vacuum tool
Four SMA-to-SMA coax cable assemblies
Headers for test points
CD-ROM
Two low-voltage, 14-pin, dual-inline package (DIP) crystal oscillators
User guide in PDF format
Example designs
♦
These designs include the Verilog source code, user constraints files (*.ucf),
documentation in PDF, and a readme.txt file
Bitstream files (*.bit) for each part type supported by the board (Bitstream
synthesized using Xilinx ISE 4.2i tools)
Full schematics of the board in both PDF format and ViewDraw schematic format
PC board layout in Pads PCB format
Gerber files in *.pho and *.pdf for the PC board (There are many free or shareware
Gerber file viewers available on the Web for viewing and printing these files)
www.xilinx.com
1-800-255-7778
Chapter 1
11
