Troubleshooting - Touch Pad
Standard Error Codes
LCD Message What's Happening?
Controller not properly secured .
****ERROR****
Excess Angle Excessive angle reached during auto operation .
Controller not properly secured .
****ERROR****
Excessive angle reached during manual operation .
Excessive Angle
Front of coach below level when starting Auto Level process
(only when trying to initiate Hitch Recognition).
****ERROR****
Touch pad power not cycled between consecutive leveling
Feature Disabled
operations .
Zero point not set .
****ERROR****
Battery voltage dropped below 9 .0V .
Low Voltage
****ERROR****
Jack has reached maximum stroke length and is unable to
lift .
Out Of Stroke
****ERROR****
Bad connection or wiring from the controller to the rear
sensor .
External Sensor
****ERROR****
Time limit exceeded for the requested auto operation .
Jack Time Out
Unable to auto level due to uneven ground .
****ERROR****
Unable to auto level due to zero point being set incorrectly .
Auto Level Fail
****ERROR****
Sensor calibration values are out of range .
Bad Calibration
****ERROR****
Internal sensor problem .
Internal Sensor
**PANIC STOP** The user pressed a button on the touch pad during an
Function Aborted automatic operation .
****ERROR****
Communication between controller and touch pad has been
lost .
Comm Error
www.lippertcomponents.com (574) 537-8900
Level-Up®
Aftermarket Manual
NOTE: To clear an error from the touch pad, repair or
otherwise correct the issue, then press "ENTER" . If the
error is still present, the message will be displayed again .
What Should Be Done?
Check and secure controller placement .
Relocate the coach .
Check and secure controller placement .
Relocate the coach .
Raise front of coach above level and restart Auto Level process .
Turn touch pad off and then back on to reset the system .
Set zero point .
Check wiring - repair or replace .
Test battery voltage under load - charge or replace .
Check disposition of jacks . Relocate the coach .
Replace or repair connection to rear remote sensor .
Check disposition of jacks .
Check disposition of jacks . Relocate the coach .
Reset zero point .
Replace controller .
Replace controller .
Restart automatic operation and then refrain from pressing any buttons
on the touch pad .
Check harness for proper connections or damage . Replace if neces-
sary .
