Endress+Hauser Proline Prosonic Flow 93 Function Manual page 61

Device functions Proline Prosonic Flow 93
Endress+Hauser
OUTPUTS
Detailed explanations and 2. Defined measuring range (
information
(Continued)
3. Flow a (—) outside, b (- -) within the measuring range.
• STANDARD
• SYMMETRY
• PULSATING FLOW
TIME CONSTANT Use this function to enter a time constant defining how the current output signal reacts to
(4005) severely fluctuating measured variables, either very quickly (enter a low time constant) or
with damping (enter a high time constant).
User input:
fixed-point number 0.01...100.00 s
Factory setting:
1.00 s
Functional description
➞
CURRENT OUTPUT (1...3)
➀ ➁
–
➀
Q
➁
+
0
+
➀
a (—): The flow components outside the scaled measuring range cannot be taken into
account for signal output.
A fault message is generated (# 351...354, current range) and the current output
responds in accordance with the parameter settings in the function FAILSAFE MODE
(4006).
b (- -): The current output signal is proportional to the measured variable assigned.
mA
This option is not available under these circumstances, because the 0_4 mA value and
the 20 mA value have different signs.
Flow components outside the measuring range are buffered, balanced and output after
a maximum delay of 60 seconds.
mA
S
7 Block OUTPUTS
➞
CONFIGURATION
➀ ➁
): and do not have the same sign.
mA
20
4
0 Q
0
➁
t
a
b
t
A
t
S = A
A0001272
A0001273
A0001274
A0001275
