9 Block BASIC FUNCTION
122
BASIC FUNCTION
WIRE LENGTH The wire length for assembling the sensors at the correct distance apart appears on the
(6885) display.
!
This option is not available unless CLAMP ON was set in the function MEASUREMENT
and the number of traverses is 1 or 3, (see function SENSOR CONFIGURATION (6882)).
Display:
max. 5-digit number, including unit (e.g. 200 mm)
SENSOR DISTANCE The distance between sensor 1 and sensor 2 as a length measurement appears on the
(6886) display.
Display:
max. 5-digit number, including unit (e.g. 200 mm)
ARC LENGTH The arc length on the pipe appears on the display.
(6887)
!
This function is not available unless INSERTION was set in the function
MEASUREMENT (6880) and the DUAL PATH option was selected in the function
SENSOR CONFIGURATION (6882).
Display:
max. 5-digit number, including unit (e.g. 200 mm)
PATH LENGTH The path length appears on the display.
(6888)
!
This function is not available unless INSERTION was selected in the function
MEASUREMENT.
Display:
max. 5-digit number, including unit (e.g. 200 mm)
Device functions Proline Prosonic Flow 93
Functional description
➞
SENSOR DATA (CH1...CH2)
Note!
Note!
Note!
➞
SENSOR PARAMETER
Endress+Hauser
