Mircom TX3 SERIES Programming Manual page 46

3.
4.
5.
6.
7.
8.
To define outputs
1.
2.
3.
4.
46 Telephone Access System Programming Manual
LT-979 Copyright 2016
Use the "#" key to define the input state as open or closed.
Press the telephone (enter) key to accept. The circuit supervision selection
appears.
Supervised for-
[ x ] No supervision
[ ] Open
[ ] Short
[ ] Open & Short
Press the arrow key to scroll to the input you wish to configure and use the
"#" key to define the input state as No supervision, Open, Short or Open &
Short
Press the telephone (enter) key. The "Input Types" selection appears.
Proceed with the rest of the input configuration or
Press info key to return to previous menu.
Press the arrow key to scroll to Outputs, and press the enter (telephone)
key. The Output selection appears.
Output Types
1 Main Door lock
2 Aux Door lock
3 GP Output 3
4 GP Output 4
Press the arrow key to scroll to the output you wish to configure and press
the telephone (enter) key. The Output Active State selection appears.
Opt Active State
< > De-energized
< x > Energized
Press the arrow key to scroll to the input you wish to configure and use the
"#" key to define the output state as energized or de-energized.
Press the telephone (enter) key. The Output selection appears.
Configuration
Version 2.4
