System introduction

2.3.4

Electrical connections

Applicable national accident prevention rules must be followed when working on the main

power supply. The electrical installation must be carried out in accordance with the

appropriate requirements.

A system architecture which supplies power to the demonstration board must be equipped

with additional control and protective devices in accordance with the applicable safety

requirements (e. g. compliance with technical equipment and accident prevention rules).

8/48

Doc ID 18293 Rev 1

UM1036
