Table 9. Bill of materials (continued)
Quan-
Reference
tity
R66, R67, R68, R69, R70,
8
R71, R74, R75
R81, R82, R88, R89, R99,
6
R101
2 R102, R105
1 R104
1 R107
1 R112
1 R113
1 R118
1 D1
D2, D8, D11, D12, D15, D16,
8
D17, D18
3 D3, D9, D19
2 D4, D6
1 D13
1 D7
1 D10
1 D5
1 D14
Q1, Q2, Q3, Q4, Q5, Q7, Q9,
10
Q10, Q11, Q12
1 Q6
1 Q8
1 Q13
1 L1
1 L2
1 U1
1 U2
1 U3
1 U4
2 U5, U10
1 U6
1 U7
Value / generic
part number
0.05 Ω
Resistor, SMD 2512, 1%, 2 W
3.9 kΩ Resistor, SMD 0805, 1%
3 kΩ Resistor, SMD 0805, 1%
2.7 kΩ Resistor, SMD 0805, 1%
180 Ω
Resistor, SMD 0805, 1%
1.2 kΩ Resistor, SMD 0805, 1%
120 kΩ Resistor, SMD 0805, 1%
1.8 kΩ Resistor, SMD 0805, 1%
Diode bridge 28.5 x 28.5 x 7.5;
GBPC3510W
wire legs, 35 A
BAT48JFILM Diode SMD
1N4148 Diode SMD, MINI-MELF
STTH1L06A Diode SMD, SMA
LED Red LED 3 mm, 2 mA, universal
BZV55C18SMD Zener diode 18 V, MINI-MELF
LED yellow LED 3 mm, 2 mA, universal
LED green LED 3 mm, 2 mA, universal
BZX84B13V Zener diode, SOT23, 13 V; 2%
BC847A NPN transistor, SOT23
BC857B PNP transistor, SOT23
STGW35NB60SD TO-247
PNP transistor 45 V / 0,5 A,
BC807-25 SMD
SOT23
330 μH
Inductive choke RM 5 mm
1.5 mH SMD choke, 1.5 mH / 1.5 A
LF33ABDT-TR Linear regulator DPAK
VIPer26LD PWM smart driver, SO-16
L78M05AB Linear regulator DPAK
M74HC14R CMOS logic, SO-14
TS3431BILT Voltage reference, SOT23
TS391ILT Op amp, SOT23-5
STGIPS20K60 IPM IGBT module
Doc ID 18293 Rev 1
Package / class
Bill of materials
Manufacturer
Welwyn
Any
Any
Any
Any
Any
Any
Any
Any
STMicroelectronics
Any
STMicroelectronics
Any
Any
Any
Any
Any
Any
Any
STMicroelectronics
FAIRCHILD
Coilcraft
Coilcraft
STMicroelectronics
STMicroelectronics
STMicroelectronics
STMicroelectronics
STMicroelectronics
STMicroelectronics
STMicroelectronics
