System introduction

2 System introduction
2.1

Main characteristics

The information listed below shows the converter specification data and the main
parameters set for the STEVAL-IHM028V1 demonstration board.
●
Minimum input voltage 125 VDC or 90 VAC
●
Maximum input voltage 400 VDC or 285 VAC
●
With applied input voltage doubler - the range from 65 VAC to 145 VAC
●
Maximum output power for applied motor up to 2000 W
●
Regenerative brake control feature
●
Input inrush limitation with bypassing relay
●
+15 V auxiliary power supply based on a buck converter with VIPer™26
●
Using IGBT intelligent power module STGIPS20K60 in SDIP 25L molded package
●
Fully populated board conception with test points and safety isolated plastic cover
●
Motor control connector for interface with STM3210B-EVAL board, STM8/128-EVAL
board, and other ST motor control dedicated kits
● Tachometer input
●
Hall/encoder inputs
● Overheating protection
●
Active fan cooling of heatsink with automatic temperature switch
●
Possibility to connect MB843 BLDC daughterboard for sensor-less six-step control
●
PCB type and size:
–
–
–
–
2.2

Target application

●
Power fans for HVAC application
●
Power tools
●
Industrial drives
●
High-power industry pumps
●
Professional washing machines.
6/48
Material of PCB - FR-4
Double-sided layout
Copper thickness: ~60 μm
Total dimensions of demonstration board: 195 mm x 175 mm.
