Autel AutoLink AL419 Manual page 15

2) From DTC Lookup screen, use the LEFT/RIGHT button to
move to the desired character, use the UP/DOWN button to
change selected digit/character and press the OK button to
confirm. (Figure 3.2)
3) View the DTC definition on screen. When DTC definition covers
more than one screen, use the LEFT/RIGHT button or
UP/DOWN
previous/next screens.

For manufacturer specific codes, you need to select a vehicle
make on an additional screen to look for DTC definitions.

If definition could not be found (SAE or Manufacturer
Specific), the scan tool displays "Please refer to vehicle
service manual!"
 For code breaker information, you need to press the "?" Help
button.
Figure 3.1
DTC Lookup
P 0 0 0 1
Left
Right
Change digit
OK Confirm
ESC Exit
［ ］［ ］- Change Digit
Figure 3.2
［ENTER］- Confirm
［ESC］- Exit
button to view
14
additional information on
