4) Use the UP/DOWN scroll button to select a trigger mode and
press the OK button.( Figure 5.21)

If data from previously tested vehicle is not erased, data from
current test will be stored in temporary cache.
5) Use the UP/DOWN scroll button to select a memory location
and press the OK button.( Figure 5.22)

The asterisk (*) icon on the screen indicates that there is a
previous recording in the memory location.

If you select a location marked with an asterisk (*) icon, a
message
displayed.( Figure 5.23)

If you do not wish to proceed with overwriting old recording,
press the OK button; if you do not wish to overwrite it, press
the ESC button, or use the LEFT/RIGHT button to select
NO and press OK to pick another memory location.
6) Observe on-screen instructions.

If Manual Trigger is selected, following screen shows:
(Figure 5.24)

If DTC Trigger is selected, following screen shows: (Figure
5.25)
7) Wait for DTC to trigger recording or press OK to start recording.
(Figure 5.26)
8) The scan tool keep recording PID data until user presses ESC
button, the selected memory location is full, or it completes
recording. A message prompting to playback data shows on the
screen. (Figure 5.27)

If you wish to playback recorded data, press the OK button; if
you do not wish to playback, press the ECS button, or use the
LEFT/RIGHT button to select NO and press the OK button
to return to Record Data menu.
prompting to
45
overwrite old recording is
