5) Use the ESC button to return to previous menu.

Recording Data

The Record Data function allows recording vehicle modules'
Parameter
intermittent vehicle problems. A recording includes 5 frames of
live data before trigger event and several frames after trigger
event.
There are two trigger modes used to record data:
A. Manual Trigger - allows user to press the OK button to start
recording.
B. DTC Trigger - automatically records PID data when a fault that
causes a DTC to set is detected by vehicle.
CAUTION: DO NOT try to drive and operate the scan tool at the
same time! Always have another person operate the scan tool
while driving.
To record live data, use the UP/DOWN scroll button to select
Record Data from Live Data menu and press the OK button.
( Figure 5.12)
Recording Complete Data Set
1) To record complete set of live data, use the UP/DOWN scroll
button to select Complete Data Set from Record Data menu
and press the OK button.
......................Live Data
DTC_CNT
FUELSYS2
ETC(℃)
SHRTFT1 (%)
Identification
0L
-40
99.2
Figure 5.19
(PID) data
40
4 .
0
?
to help diagnose
