Pressing SHIFT temporarily allows the Pattern Length to be adjusted in fine increments
→
according the value of the Step Grid.
7.8

Importing/Exporting Audio and MIDI to/from Patterns

In the Pattern Editor you can quickly export MIDI and audio from Patterns and import MIDI to
Patterns via drag and drop.
7.8.1

Exporting Audio from Patterns

The Audio drag-and-drop function allows you to export audio from the selected Pattern onto
your desktop or into your host software by simply dragging it onto the target location or appli-
cation. This function is only available in the software.
The audio will be exported as a WAV audio file and according to the current settings of the
Export Audio panel (see section
tings) with following exceptions:
▪ The exported range will be based on the selected Pattern, regardless of the current Loop
Range. Note that the
▪ The exported audio will only include the focused Group (in Group view) or the focused
Sound (in Keyboard view) — in other words it will include what you see in the Event area.
▪ The audio file will be named as follows:
◦ Export in Group view: [Group name] - [Pattern name] - [BPM].wav
◦ Export in Keyboard view: [Group name] - [Pattern name] [Sound name] - [BPM].wav
To render Patterns to audio files:
1. Select the Pattern you want to export audio from (see section
and Pattern Banks).
2. If you want to export multiple Sounds of the Group, switch the Pattern Editor to Group
view, mute the Sounds you want to exclude from the exported audio file (see section
↑5.4.1, Mute and
exported audio file will be silent!
↑4.4.3, Exporting Audio
Loop Optimize setting will be respected.
Solo), and check that the Group itself is not muted — otherwise the
Importing/Exporting Audio and MIDI to/from Patterns
for more information on these set-
↑7.7.2, Selecting Patterns
MASCHINE - Manual - 400
Working with Patterns
