YAK 3
Instruction Manual.
WING ASSEMBLY.
Please see below pictures.

INSTALLING THE AILERON SERVOS.

Attach the aluminum tube into wing.
Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
1) Using a small weight (Weighted fuel
pick-up works well) and string, feed the
string through the wing as indicated.
Note : to be convenience for trans-
2) Place the servo between the mounting
ports ,you don't need to do this steps.
blocks and space it from the hatch. Use a
pencil to mark the mounting hole loca-
tions on the blocks.
6
