Secure the landing gear doors to the
landing gear struts.
M3x10 mm
Collar.

INSTALLING THE FUSELAGE SERVOS.

Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
1) Install the rubber grommets and brass
collets onto all servos. Test fit the servos
into the servo mounts.
2) Secure the servos with the screws pro-
vided with your radio system.
Elevator servo.
Rudder servo.
.
Throttle servo.
