The purpose of using a posture belt for positioning,
is to position the user and to give him / her a better
posture.
CAUTION!
Risk of sliding
– If you have a very low seat height and / or
use your feet to maneuver the wheelchair, the
legrests can be removed. If so, be aware of the
sliding risk!
A
C
1. Loosen and remove the screw and the washer C for the
legrest attachment.
2. Place the attachment A on the frame as shown on
the picture.
3. Adjust the attachment to the required position.
4. Use the screw and the washer C to fixate the
attachment A and tighten the screw.
The positioning belt should be placed in the slot B
on the attachment A.
WARNING!
Risk of injury
– The attachment A must not be used for safety
belts when transferring the user in a vehicle.

5.21 Privacy attachment

Attach the privacy attachment on the velcro, both on the
seat and on the backrest (see picture).
1488727-M
B

5.22 Harness

WARNING!
Risk of choking
When the wheelchair is tilted or reclined the
harness can move and cause hazard to the user.
– Make sure that the harness is correctly
positioned after each adjustment.
WARNING!
Safety risk
– The harness which is used with the harness
attachment holder, should be fitted by an
experienced clinician or technician.
– The harness must always be used in combination
with the pelvic belt and should be worn on top
of the pelvic belt.
WARNING!
Risk of sliding
The user may accidently slide down in the
wheelchair.
– Always use a harness in combination with a
pelvic belt.
WARNING!
Safety risk
– The harness must not be used as a safety belt
during transport in a vehicle.
Make sure that the harness does not put too much
pressure on any point.
Belts/harnesses which are CE-marked for the purpose
of using on wheelchairs, can be mounted on the
chair with preserved CE-marking. The belt/harness
should be fitted by the responsible prescriber and be
mounted by an experienced technician. However,
when transporting the wheelchair in a vehicle,
Invacare's original pelvic belt must be used as a
complement to the safety belt in the vehicle!

5.22.1 Harness attachment holder

A
1. Loosen the handwheel and remove the neckrest.
2. Fasten the harness holder onto the neckrest pole.
3. Re-tighten the handwheel.
The harness is mounted on the holder for the
harness.
4. Thread the straps through the harness holder A and
the harness clamp B.
Accessories
B
C
D
E
