2 Mechanical Installation
2.1 Before Starting
2.1.1 Checklist
When unpacking the frequency converter, make sure that the unit is un-
damaged and complete. Check that the packaging contains the following:
•
VLT Micro Drive FC 51
•
Quick Guide
Optional: LCP and/or de-coupling plate.
2.2 Side-by-Side Installation
The frequency converter can be mounted side-by-side for IP 20 rating units and requires 100 mm clearance above and below for cooling. Regarding
surroundings in general, please see chapter
Illustration 2.1: Side-by-side installation.
7. Specifications
.
®
MG.02.A4.02 - VLT
is a registered Danfoss trademark
Illustration 2.1: Content of box.
