VLT Micro Drive FC 51 Operating Instructions
6-22 Terminal 60 Low Current
Range:
[0.00 - 19.99 mA]
6-23 Terminal 60 High Current
Range:
[0.01 - 20.00 mA]
6-24 Terminal 60 Low Feedback Value
Range:
[-4999 - 4999]
6-25 Terminal 60 High Feedback Value
Range:
[-4999 - 4999]
6-26 Terminal 60 Filter Time Constant
Range:
[0.01 - 10.00 s]
7-20 Process CL Feedback Resource
Range:
[]
7-30 Process PI Normal/Inverse
Range:
[]
7-31 Process PI Anti Windup
Range:
[]
7-32 Process PI Start Speed
Range:
[0.0 - 200.0 Hz]
7-33 Process PI Proportional Gain
Range:
[0.00 - 10.00]
7-34 Process PI Integral Time
Range:
[0.10 - 9999.00 s]
Function:
Normally set to 0 or 4 mA.
Function:
Normally (default) set to 20 mA.
Function:
Value corresponding to P. 6-22 setting.
Function:
Value corresponding to P. 6-23 setting.
Function:
Filter for suppressing electrical noise.
Function:
Choose [2] analog input 60.
Function:
Most PI controllers are "Normal".
Function:
Leave Enabled normally.
Function:
Choose expected normal running speed.
Function:
Enter the P-factor.
Function:
Enter the I-factor.
®
