4 Programming

4.4 Quick Menu Parameters

4.4.1 Quick Menu Parameters - Basic Settings QM1
Below are descriptions of all parameters found in the Quick Menu.
＊ = Factory setting.
4
1-20 Motor Power [kW]/[HP] (P
Option:
[1] 0.09 kW/0.12 HP
[2] 0.12 kW/0.16 HP
[3] 0.18kW/0.25 HP
[4] 0.25 kW/0.33 HP
[5] 0.37kW/0.50 HP
[6] 0.55 kW/0.75 HP
[7] 0.75 kW/1.00 HP
[8] 1.10 kW/1.50 HP
[9] 1.50 kW/2.00 HP
[10] 2.20 kW/3.00 HP
[11] 3.00 kW/4.00 HP
[12] 3.70 kW/5.00 HP
[13] 4.00 kW/5.40 HP
[14] 5.50 kW/7.50 HP
[15] 7.50 kW/10.0 HP
[16] 11.00 kW/15.00 HP
NB!
Changing this parameter affects par. 1-22 to 1-25,
1-30, 1-33 and 1-35.
1-22 Motor Voltage (U
Range:
230/400 V [50 - 999 V]
1-23 Motor Frequency (f
Range:
50 Hz* [20-400 Hz]
20
)
m.n
Function:
Enter motor power from nameplate data.
Two sizes down, one size up from nominal VLT rating.
)
m.n
Function:
Enter motor voltage from nameplate data.
)
m.n
Function:
Enter motor frequency from nameplate data.
