Mechanical Dimensions - Danfoss VLT Micro Drive FC 51 Series Operating Instructions Manual

2 Mechanical Installation

2.3.1 Mechanical Dimensions

2
Illustration 2.1: Mechanical dimensions.
NB!
A template for drilling can be found on the flap of the packaging.
1 X 200-240
Frame
V
M1 0.18 - 0.75
M2 1.5
M3 2.2
Table 2.1: Mechanical Dimensions
1)
For LCP with potentiometer, please add 7.6 mm.
NB!
DIN rail mounting kit is available for M1 frame . Please use ordering number 132B0111.
10
Power (kW)
3 X 3 X
A
200 -240 V 380-480 V
0.25 - 0.75 0.37 - 0.75 150
1.5 1.5 - 2.2 176
2.2 -3.7 3.0 - 7.5 239
MG.02.A4.02 - VLT
®
VLT Micro Drive FC 51 Operating Instructions
Height (mm) Width (mm)
A (incl. decou-
a B
pling plate)
205 140.4 70
230 166.4 75
294 226 90
®
is a registered Danfoss trademark
1) Max.
Depth
Weight
(mm)
b C Kg
55 148 1.1
59 168 1.6
69 194 3.0
