3 Electrical Installation
For EMC correct installation, use optional de-coupling plate, see chapter
Options for frequency converter
3
3.4 Control Terminals
3.4.1 Access to Control Terminals
All control cable terminals are located underneath the terminal cover in
front of the frequency converter. Remove the terminal cover using a
screwdriver.
NB!
See back of terminal cover for outlines of control terminals and switches.
14
.
MG.02.A4.02 - VLT
®
VLT
Micro Drive FC 51 Operating Instructions
Illustration 3.5: Frequency converter with de-coupling plate
Illustration 3.6: Removing terminal cover.
®
is a registered Danfoss trademark
