5 Modbus RTU
Bit 03, Coasting:
Bit 03 = "0" shuts off the output transistors causing the motor to coast to a standstill.
Bit 03 = "1" enables the frequency converter to start the motor if the other starting conditions have been fulfilled.
NB!
In par. 8-50
Bit 04, Quick stop:
Bit 04 = "0" causes a stop, in which the motor speed is ramped down to stop via 9ar. 3-81
Bit 05, Hold output frequency:
Bit 05 = "0" causes the present output frequency (in Hz) to freeze. The frozen output frequency can then be changed only by means of the digital inputs
5
(par. 5-10 to 5-15) programmed to
NB!
If Freeze output
• Bit 03 Coasting stop
• Bit 02 DC braking
• Digital input (par. 5-10 to 5-15) programmed to
Bit 06, Ramp stop/start:
Bit 06 = "0" causes a stop, in which the motor speed is ramped down to stop via the selected ramp down parameter.
Bit 06 = "1" permits the frequency converter to start the motor, if the other starting conditions have been fulfilled.
NB!
In par. 8-53
input.
Bit 07, Reset:
Bit 07 = "0" does not cause a reset.
Bit 07 = "1" causes the reset of a trip. Reset is activated on the signal's leading edge, i.e. when changing from logic "0" to logic "1".
Bit 08, Jog:
Bit 08 = "1" causes the output frequency to be determined by par. 3-19
Bit 09, Selection of ramp 1/2:
Bit 09 = "0" means the ramp 1 is active (par. 3-40 to 3-47).
Bit 09 = "1" means that ramp 2 (par. 3-50 to 3-57) is active.
Bit 10, Data not valid/Data valid:
Is used to tell the frequency converter whether the control word is to be used or ignored.
Bit 10 = "0" causes the control word to be ignored.
Bit 10 ="1" causes the control word to be used.
Bit 11, Relay 01:
Bit 11 = "0" Relay 01 not activated
Bit 11 = "1" Relay 01 is activated, provided
36
Coasting select
a selection is made to define how Bit 03 gates with the corresponding function on a digital input.
Speed up Speed down
and .
is active, the frequency converter can only be stopped by the following:
DC braking
Start select
a selection is made to define how Bit 06
Control word Bit 11 has been chosen in par. 5-40
MG.02.A4.02 - VLT
®
VLT Micro Drive FC 51 Operating Instructions
Quick stop ramp time
, Coasting stop or Reset and coasting stop.
Ramp stop/start
gates with the corresponding function on a digital
Jog speed
.
Function relay
®
is a registered Danfoss trademark
.
.
