Search word: If the plant code is known, it is possible to find the
plant data stored with help of a search machine.
Select hereto "Search word" and confirm with <Enter>. Using the
software keyboard, input at least 3 connected figures of the plant:
Example: "25.09" for plant code 25.09.2009
After input completion, press <F1> to
start the search. All files matching this
code will be filtered. The resulting selec-
tion can be scrolled using the cursor
keys (F1 for selection start, F2 for selec-
tion end). Once found, activate the de-
sired data record with <Enter>. The last
measurement on this plant can be
viewed pressing
memory" / <Enter>. All measured and
calculated values can be called up on 5
display pages, using the cursor keys to
step thru.
Memory number 1
25.09.2009
12:15 25.09.09
O2 value in air
19.5
O2
CO
0.01
Draught
O2 value in air 12:15 25.09.09
Memory number 1
Press <ESC> to escape the previous measurement data and the
recording of the current data can start.
