PCI-DAC6702 and PCI-DAC6703 User's Guide

Connecting the board for I/O operations

Connectors, cables – main I/O connector
The table below lists the board connectors, applicable cables, and compatible accessory products for the PCI-
DAC6702 and PCI-DAC6703.
Connector type
Compatible cables
Compatible accessory products with the
C100HD50-x cable
Compatible accessory products with the
C100MMS-x cable
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections. This document is available on our web site at
www.measurementcomputing.com/signals/signals.pdf.
Board connectors, cables, and accessory equipment
Shielded, SCSI 100-pin D-type
C100HD50-x unshielded round cable. x = 3 or 6 feet. (Figure )
C100MMS-x shielded round cable. x = 1, 2, or 3 meters. (Error! Reference
source not found.)
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
BNC-DI-FE
12
Installing the PCI-DAC6702 and PCI-DAC6703
