PCI-DAS64/M1/16 User's Guide
Calibrate the PCI-DAS64/M1/16 after it has warmed up and immediately before making critical
measurements
Use the InstaCal utility to calibrate the PCI-DAS64/M1/16 after it has fully warmed up. For best results,
calibrate the board immediately before making critical measurements. The high resolution analog components
on the board are somewhat sensitive to temperature. This pre-measurement calibration insures that your board is
operating at the optimum calibration values.
Configuring the PCI-DAS64/M1/16
All hardware configuration options on the PCI-DAS64/M1/16 are software controlled. You can select some of
the configuration options using InstaCal, such as the analog input configuration (64 single-ended or
32 differential channels), and the edge used for triggering when using an external pacer.
Once configured, any program that uses Measurement Computing's Universal Library will initialize the
hardware according to these selections.
Connecting the board for I/O operations
Connectors, cables – main I/O connector
Table 2-1
lists the board connectors, applicable cables and compatible accessory boards.
Parameter
Connector type
Compatible cables — main connector
Compatible cables — 40-pin auxiliary
connector
Compatible accessory products using
the C100HD50-x cable
Compatible accessory products using
the C100MMS-x cable
Compatible accessory products using
the C40FF-x cable
Compatible accessory products
with the C40-37F-x cable
or
with the BP40-37-x and the C37FF-x
or C37FFS-x cable
Table 2-1. Main board connector, cables, accessory equipment
Specification
Main connector: Shielded SCSI 100-pin D-type
Auxiliary DIO connector: 40-pin header connector
! C100HD50-x, unshielded ribbon cable. x = 3 or 6 feet.
! C100MMS-x, shielded round cable. x = 1, 2, or 3 meters.
! C40FF-x
! C40-37F-x
! BP40-37-x
CIO-MINI50 (two required)
SCB-50
CIO-TERM100
SCB-100
CIO-MINI40
SCB-37
CIO-MINI37
CIO-TERMINAL
CIO-ERB24
CIO-ERB08
SSR-RACK24
SSR-RACK08
2-3
Installing the PCI-DAS64/M1/16
