PCI-DAC6702 and PCI-DAC6703 User's Guide
Pin Signal Name
1 AGND
2 VCH0
3 AGND0
4 VCH1
5 AGND1
6 VCH2
7 AGND2
8 VCH3
9 AGND3
10 VCH4
11 AGND4
12 VCH5
13 AGND5
14 VCH6
15 AGND6
16 VCH7
17 AGND7
18 AGND
19 VCH8
20 AGND8
21 VCH9
22 AGND9
23 VCH10
24 AGND10
25 VCH11
26 AGND11
27 VCH12
28 AGND12
29 VCH13
30 AGND13
31 VCH14
32 AGND14
33 VCH15
34 AGND15
35 n/c
36 n/c
37 n/c
38 n/c
39 PC 5V
40 DIO0
41 DIO1
42 DIO2
43 DIO3
44 n/c
45 DIO4
46 DIO5
47 DIO6
48 DIO7
49 n/c
50 GND
Note: DIO[7:0] signals are provided in two locations in order to provide flexibility for
Note 3:
applications which use the C100HD50-x ribbon cable.
Table 11. PCI-DAC6703 pin out
Pin Signal Name
51 AGND
52 n/c
53 AGND
54 n/c
55 AGND
56 n/c
57 AGND
58 n/c
59 AGND
60 n/c
61 AGND
62 n/c
63 AGND
64 n/c
65 AGND
66 n/c
67 AGND
68 AGND
69 n/c
70 AGND
71 n/c
72 AGND
73 n/c
74 AGND
75 n/c
76 AGND
77 n/c
78 AGND
79 n/c
80 AGND
81 n/c
82 AGND
83 n/c
84 AGND
85 DIO0
86 DIO1
87 DIO2
88 DIO3
89 DIO4
90 DIO5
91 DIO6
92 DIO7
93 n/c
94 n/c
95 n/c
96 GND
97 n/c
98 n/c
99 n/c
100 GND
