CIO-DIO96 User's Guide

Installing the CIO-DIO96

After you configure the base address, you can install the CIO-DIO96 into your computer. Follow the steps
below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install
the MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on
installing the software.
1.
Turn your computer off, open it up, and insert your board into an available ISA slot.
2.
Close your computer and turn it on.
3.
To test your installation and configure your board, run the InstaCal utility you installed in the previous
section. Refer to the Quick Start Guide that came with your board
Software-Quick-Start.pdf

Connecting the board for I/O operations

Connectors, cables – main I/O connector
The table below lists the board connector, applicable cables, and compatible accessory products.
Connector type
Compatible cables
Compatible accessory products
with the C50FF-x cable
for information on how to initially set up and load InstaCal.
Board connector, cables, and accessory equipment
(2) 50-pin shrouded male header connectors: P1 and P2
C50FF-x
CIO-TERM100-pin
CIO-SPADE50
CIO-MINI50
SSR-RACK24, SSR-RACK48
CIO-ERB24, CIO-ERB48
11
Installing the CIO-DIO96
