Appendix C: LED Indications (Programmable Keys)

LED indications visually show the state of certain features. LEDs typically indicate that a feature is either activated (steady
on) or is pending further commands or needs additional information (flashing). The LED indications usually go hand-in-hand
with various messages when equipped with a display.
LED Indications
Off
Wink
Flashing
Steady On
Message Lamp
MUTE and SPKR
NOTE! In special cases the key may operate differently. See the relevant feature for explanations of
various messages that can appear.
Appendix C: LED Indications (Programmable Keys)
Indicates that the feature is inactive or the DSS destination is idle.
A signal that flashes at a fast rate of 120 pulses per minute (400/100mS). Typically
indicates that a call is on hold, normally the telephone does not ring.
A signal that flashes at a slow rate of 60 pulses per minute (800/200mS). Typically
indicates that a call is pending, in most cases the station will also ring.
Indicates that a key is active. When defined as DSS, indicates that the user
associated with the DSS key is in use. When defined as a line or speaker indicates
that a call is in progress.
Dedicated LED for message waiting indication.
See Using the Fixed Function Keys on page
87
Description
20.
T207M / T208M User Guide
