SmartNode 4830 Getting Started Guide
1. Configure IP address
Power connection and default configuration
The factory default configuration for the Ethernet IP addresses and network masks are listed in
Ethernet interfaces are activated upon power-up. LAN interface ETH 0/1 (LAN) provides a default DHCP server.
Table 10. Factory default IP address and network mask configuration
WAN interface Ethernet 0 (ETH 0/0)
LAN interface Ethernet 1 (ETH 0/1)
DHCP address range
Both Ethernet interfaces are activated upon power-up.
If these addresses match with those of your network, go to section
on page 47. Otherwise, refer to the following sections to change the addresses and network masks.

Connect with the serial interface

The Console port is wired as an EIA-561, RS-232 port. Use the included Model 16F-561 adapter and cable (see
figure 24) between the SmartNode's Console port and a PC or workstation's RS-232 serial interface. Activate the
terminal emulation program on the PC or workstation that supports the serial interface (e.g. HyperTerm).
Terminal emulation program settings:
• 9600 baud
• no parity
• 8 bit
• 1 stop bit
• No flow control

1. Configure IP address

192.168.1.10–192.168.1.19
e r
u t
R o
e
a y v i c
t e w D e
G a
s s
c e
I P
V o
A c
4 e d
5 2
a t
g r
e 4
t e
o d I n
o le
I P
t N n s
T o
a r C o
S m
r ts
P o
ic e
V o
1
e t
E n
e t 0
E n
Figure 24. Connecting to the terminal
4 • Getting started with the SmartNode
IP Address
DHCP
192.168.1.1
"2. Connect the SmartNode to the network"
Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode 4000 Series device
table 10. Both
Network Mask
DHCP
255.255.255.0
255.255.255.0
Serial Terminal
45
