SmartNode 4830 Getting Started Guide

Software tools

You will need a PC (or equivalent) with a VT-100 emulation program (e.g. HyperTerminal) to configure the
software on your SmartNode VoIP IAD.

Power source

If you suspect that your AC power is not reliable, for example if room lights flicker often or there is machinery
with large motors nearby, have a qualified professional test the power. Install a power conditioner if necessary.

Location and mounting requirements

The SmartNode VoIP IAD is intended to be placed on a desktop or similar sturdy, flat surface that offers easy
access to the cables. Allow sufficient space at the rear of the chassis for cable connections. Additionally, you
should consider the need to access the unit for future upgrades and maintenance.

Installing the VoIP IAD

SmartNode VoIP IAD installation consists of the following:
• Placing the device at the desired installation location (see section
• Installing the interface and power cables (see section
When you finish installing the SmartNode, go to chapter 4,

Mounting the VoIP IAD

Place the VoIP IAD on a desktop or similar sturdy, flat surface that offers easy access to the cables. The VoIP
IAD should be installed in a dry environment with sufficient space to allow air circulation for cooling.
Note

Connecting cables

WARNING
CAUTION
Installing VoIP IAD cables takes place in the following order:
1. Installing the RJ-11 voice port (FXS) cable or cables (see section
IAD's FXS and FXO interface ports"
2. Installing the 10/100 Ethernet port cable or cables (see section

Installing the VoIP IAD

For proper ventilation, leave at least 2 inches (5 cm) to the left, right,
front, and rear of the SmartNode VoIP IAD.
Do not work on the system or connect or disconnect cables during periods of
lightning activity.
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
on page 33)

"Mounting the VoIP IAD"

"Connecting cables"

on page 32)
"Getting started with the SmartNode"
"Installing an interface cable on the VoIP
"Installing the Ethernet cable"
3 • Hardware installation
on page 32)
on page 43.
on page 35)
32
