Installing the DSL interface cable. The SmartNode Model 4830 comes with an option for a G.SHDSL or
ADSL interface. Use a straight-through RJ-11 cable to connect the DSL port.
Installing the V.35 interface cable. The SmartNode Model 4830 comes with a V.35 interface presented on a
DB-25 female connector (see
Figure 16. Rear view of the SN4830 showing location of V.35 interface connector
The signal pin-outs for the Model 4830 V.35 interface are shown in
Table 7. Signal pin-outs for the V.35 interface on the SmartNode 4830
Pin
1
2
3
4
5
6
7
8
9
11
The SN4830's V.35 interface is wired as a DTE. No DCE configuration is possible. If you are directly connect-
ing the SN4830's V.35 interface to third-party equipment that cannot be configured as a DCE, you must use a
Installing the VoIP IAD
figure
16).
Signal
Frame Ground
TXDa
RXDa
RTS
CTS
DSR
Signal Ground
DCD
RXCb
EXTCb
V.35 serial port connector
table
7.
Pin
Signal
12
TXCb
14
TXDb
15
RXCa
16
RXDb
17
RXCa
18
LL
20
DTR
21
RL
24
EXTCa
3 • Hardware installation
