SmartNode 4830 Getting Started Guide

Connecting to external power source

The VoIP IAD comes with an internal or external power supply. This section describes installing the power
cord into the VoIP IAD. Do the following:
Note
1. If your unit is equipped with an internal power supply, go to step 2. Otherwise, insert the barrel type con-
nector end of the AC power cord into the external power supply connector (see
2. Insert the female end of the power cord into the internal power supply connector (see
DC power connector
CAUTION
3. Verify that the AC power cord included with your VoIP IAD is compatible with local standards. If it is not,
refer to chapter 6, "Contacting Patton for assistance"
patible power cord.
4. Connect the male end of the power cord to an appropriate power outlet.
Installing the VoIP IAD
Do not connect the power cord to the power outlet at this time.
Figure 21. Power connector location on rear panel
The VoIP IAD power supply automatically adjusts to accept an
input voltage from 100 to 240 VAC (50/60 Hz).
Verify that the proper voltage is present before plugging the
power cord into the receptacle. Failure to do so could result in
equipment damage.
on page 56 to find out how to replace it with a com-
3 • Hardware installation
figure 21).
figure 21).
41
