Planmeca ProMax 3D s User Manual page 23

Detaching sensor from C-arm
C-arm
electrical
connector
Sensor
Locking
knob
User's Manual (3D)
3. Push in the C-arm electrical connector button on the
C-arm electrical
connector button
NOTE Do not remove the sensor during imaging process.
1. Push in the C-arm electrical connector. This will
2. Turn the locking knob 180 degrees. This will release
3. Carefully pull the sensor out.
Planmeca ProMax 3D s & 3D Classic with ProTouch 19
other side. This will make the electrical connection
between the sensor and C-arm.
disconnect the electrical connection between the
sensor and C-arm.
the locking mechanism.
3D PATIENT EXPOSURE
