MAIN PARTS
Settings
Estimated values
black
Actual values
green
14 Planmeca ProMax 3D s & 3D Classic with ProTouch
Forward
Fast
forward
Accept
Cancel
Pause
NOTE You can switch demo mode on if you wish to practice
• To accept a selection and to go to the next screen,
touch the forward button.
• To accept a selection and to skip the next screen,
touch the fast forward button.
• To accept a selection, touch the green check mark
button.
• To cancel a selection, touch the red cross button.
• To pause a function (instead of cancelling it), touch the
pause button.
• To scroll a list down or up, slide your finger on the
screen.
• To change a setting, select the settings icon at the top
left corner of the main view. This takes you to the
settings menu where you can adjust the settings of the
X-ray unit. Refer to section 12 "SETTINGS" on page
50 for details.
The screen will automatically switch to stand-by mode if
you do not touch the screen or the exposure button for
more than thirty minutes. In stand-by mode the green light
on the exposure button indicates that the X-ray unit is
switched on even though the screen is dark. The screen
will switch on as soon as you touch it again.
The estimated values for exposure time, DAP (Dose Area
Product) and CTDI (Computed Tomography Dose Index)
are shown with black text on the touch screen before you
take an exposure. The actual values are shown with
green text after the exposure.
or demonstrate the functions of the X-ray unit without
radiation (Settings > User > 1300 Operational settings
> 1310 User Mode > 1311 Set Demo Mode).
