About This Appendix
This appendix presents the mechanical specifications for the SolarEdge
power optimizers.
Use M8 screws and washers to secure the power optimizer units to the
racking.
NOTE
:
SolarEdge does not provide the screws, nuts or washers because the required
sizes and lengths vary for different racks.
CAUTION:
Before installing directly on the module or module frame, first consult the module
manufacturer for information about the proper positioning and its impact on the
module warranty.

Mark all mounting hole locations.

Each power optimizer must be attached to the rack using both mounting
holes.

Drill the holes.
CAUTION:
Do not drill through the power optimizer or through the mounting holes. The strong
vibrations created by the drill can damage the power optimizer.
