Chapter 5, Replacing And Adding System Components; Modifying An Existing Installation - SolarEdge Power Harvesting System Installation Manual

SolarEdge Installation Guide for Three Phase Inverters – EU – Version 1.5

Modifying an Existing Installation

This section describes how to modify an existing installation that has been
operating properly for a while.
►
To modify an existing installation:
1 Shut down the inverter by turning OFF its ON/OFF switch and the DC
switch of the main circuit board. The inverter goes into Shutdown
mode and displays the following message:
D C
D O
This message is displayed until the DC is safe. The default safety
voltage is 50 V.
WARNING!
Do not touch the DC power connections until the DC voltage is at a safe level.
Doing so may cause personal damage, damage to the device and/or danger of
fire.
2 Switch off the AC to the inverter.
WARNING!
If you cannot see the inverter panel, or there is a malfunction indicated on the
LCD panel, then switch off the AC to the inverter and wait five minutes for the
input capacity of the inverter to discharge.
Replacing and Adding
System Components
V O L T A G E
N O T D I S C O N N E C T !
V D C :
Replacing and Adding System Components
Chapter 5
N O T S A F E !
7 2 . 0
46
