SolarEdge Installation Guide for Three Phase Inverters – EU – Version 1.5
2 Turn on the inverter ON/OFF switch at the bottom of the inverter
within five seconds. If you do not turn ON the inverter ON/OFF switch
within five seconds, the inverter then exits pairing mode.
The following screen is then displayed indicating that the inverter is
performing the process of pairing and is assigning power optimizers to
the inverter.
R e m a i n i n g
This message displays a countdown of the seconds until it completes
the pairing process. If pairing fails, an error is displayed. This error
appears only if the above steps were not followed. If an error appears,
then follow the pairing steps again.
After commissioning succeeds, the following message is displayed:
P a i r i n g
3 Since at this stage the ON/OFF switch at the bottom of the inverter is
ON, the power optimizers start producing power and the inverter starts
converting AC.
WARNING
!
After you turn ON the ON/OFF switch of the Three Phase Inverter, the DC
cables carry a high voltage and the power optimizers no longer output a safe 1
V output.
If the inverter starts converting after the initial connection to the AC,
the inverter then goes into Standby mode until enough power is
generated (the inverter LED flickers green). While the inverter is in
Standby mode, the following message is displayed:
W a k i n g
R e m a i n i n g :
P a i r i n g
[ S e c ] :
P a i r i n g
C o m p l e t e d
U P . . .
0 5 1 S e c
Commissioning the Installation
1 0 4
