SolarEdge Installation Guide for Three Phase Inverters – EU – Version 1.5
Closing the Cover
►
To close the cover:
1 Make sure to reattach the chassis grounding wire, if it was removed.
Figure 16: Chassis Grounding Wire Conection
2 Shut the chassis cover and secure it by tightening the screws.
3 For proper sealing, first tighten the corner screws and then the two central
screws. The recommended order can be seen in the following figure:
#1
#6
#3
Figure 17: Tightening the Screws
Grounding cable for cover
#2
#5
#4
Installing the Inverter
35
