SolarEdge Installation Guide for Three Phase Inverters – EU – Version 1.5
4 Select the 4. Display option to display the following three options:

4.1 LCD On Time <30>: Specifies the number of seconds that the
LCD panel backlight is ON after the LCD light button is pressed.
<30> represents the default value of 30 seconds.

4.2 TLM On Time <15>: Specifies the number of minutes that the
LCD panel backlight is ON while viewing the Telemetry window.
The default is 15 minutes.

4.3 SW Version: Displays version information describing various
firmware inverter processors, as follows:
I D :
D S P 1
D S P 2
C P U

ID: Displays the inverter ID, which should be the same as on
the inverter. You may refer to the Identifying the Inverter
section on page 25 for more details.

The next three numbers represent the firmware versions of
various processors.
NOTE:
Please have these numbers ready when you contact SolarEdge support.
5 Select the 5. Communication option to define and configure the
communication option used by the inverter to communicate with the
SolarEdge Monitoring Server.
* 1 . S e r v e r
2 . L A N
3 . R S 4 8 5
4 . Z i g B e e

Select option 5.1. Server to select which communication method is
used to communicate between this inverter and the SolarEdge
Monitoring Portal.
0 0 0 0 0 0 0 F
V e r :
V e r :
V e r :
< L A N >
C o n f
C o n f
C o n f
Inverter User Interface
1 . 8 8
0 . 8 1
1 . 4 7 2 7
