SolarEdge Home Hub Single Phase Inverter Top
Only Replacement Manual — North America
Revision history
Version 1.0, October 2024; Initial release date.
Contents
Overview ....................................................................................................................................................................................................................... 1
IMPORTANT SAFETY INSTRUCTIONS ................................................................................................................................................................ 1
INSTRUCTIONS DE SÉCURITÉ IMPORTANTES ................................................................................................................................................ 2
Required equipment ................................................................................................................................................................................................ 2
Before you begin ....................................................................................................................................................................................................... 2
Test for safe voltages ............................................................................................................................................................................................... 3
Uninstall the top of the inverter .......................................................................................................................................................................... 3
Install the new top of the inverter ...................................................................................................................................................................... 5
Reinstall communications components ............................................................................................................................................................ 7
Reinstall inverter covers .......................................................................................................................................................................................... 8
Power ON the inverter ............................................................................................................................................................................................ 8
Recommission the inverter .................................................................................................................................................................................... 8
Overview
The application note explains how to replace the top part of the SolarEdge Home Hub
inverter. You must install the inverter top on the original Safety Switch to maintain
compatibility with the installed LG Chem RESU10h second generation batteries.
IMPORTANT SAFETY INSTRUCTIONS
WARNING !
Configuration of the power control settings system or changes to settings shall be
made by qualified personnel only. Incorrect configuration or setting of the power
control settings may result in unsafe conditions.
WARNING !
The controlled current settings shall not exceed the busbar rating or conductor
ampacity of any PCS controlled busbar or conductor.
WARNING !
The maximum operating currents in controlled busbars or conductors are limited
by the settings of the power control system (PCS) and may be lower than the sum
of the currents of the connected controlled power sources. The settings of the PCS
controlled currents may be used for calculation of the design currents used in the
relevant sections of NEC Article 690 and 705.
Replace Top of Home Hub Inverter — North America
Version 1.0, October 2024
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SolarEdge Home Hub Series
Summary of Contents for SolarEdge Home Hub Series
- Page 1 Recommission the inverter ....................................8 Overview The application note explains how to replace the top part of the SolarEdge Home Hub inverter. You must install the inverter top on the original Safety Switch to maintain compatibility with the installed LG Chem RESU10h second generation batteries.
- Page 2 Version 1.0, October 2024 INSTRUCTIONS DE SÉCURITÉ IMPORTANTES AVERTISSEMENT ! La configuration du système sur le contrôle des puissances ou les modifications des réglages ne doivent être effectuées que par du personnel qualifié. Une configuration ou un réglage incorrect des paramètres de contrôle de puissance peut entraîner des conditions dangereuses.
- Page 3 Version 1.0, October 2024 Test for safe voltages Before you disconnect any wires in the DC Disconnect (DCD) unit, you must test for safe voltages. Test at the DC terminals or in the upper cabinet to confirm that the switch is functioning properly and that the strings have the correct voltage.
- Page 4 Version 1.0, October 2024 Step 2: Remove the DC and AC conductors. 1. Cut off the zip ties from the ferrite ring (choke) with the wire cutters. 2. Remove the four screws with the #1 Philips screwdriver to detach DC conductors from the power board.
- Page 5 Version 1.0, October 2024 Step 4: Detach the top of the inverter. 1. Pull the two locking clips outward to detach the top half of the inverter to the DCD unit. 2. Remove the seismic screws on both sides of the inverter connecting it to the wall mount. 3.
- Page 6 Version 1.0, October 2024 4. Guide communication cables through the left opening in the new inverter. 5. Reattach the metal clips to the inverter mounting pins on top of DCD unit to connect the top to the bottom of the inverter. Step 2: Reconnect the DC and AC conductors.
- Page 7 Version 1.0, October 2024 4. Verify that the AC and DC wires are correctly landed and secured with the correct torque. Check that you correctly reinstalled the DC and AC cable connections with the photo Reinstall communications components 1. Reinstall any accessories (Home net card, Cellular modem, or Zigbee module) from the previous unit.
- Page 8 Version 1.0, October 2024 Reinstall inverter covers 1. Reinstall both the front covers of both the inverter and DCD unit. Install new seismic screws. 2. Tighten the covers with seismic screws. 3. Record the new serial number for later use. Power ON the inverter 1.
- Page 9 After the commissioning process is finished, confirm that the new inverter is registered under the site in the Monitoring platform. Return the old inverter top to SolarEdge with the provided shipping label. For any troubleshooting issues, contact SolarEdge support. To view Top Replacement: SolarEdge Home Hub Inverter video, scan the QR code:...
