The SolarEdge Monitoring Server also enables you to display a logical and
physical schematic layout of the installed power optimizers, as follows:

Logical Layout: Shows a schematic logical layout of the components
in the fields, meaning inverters, clusters, strings and panels and their
electrical connectivity. This view enables you to see a logical view of
which panels are connected in each string, which strings are connected
to each inverter and so on.

Physical Layout: Shows a schematic physical layout of the
components in the fields, meaning inverters, clusters, strings and panels
and their electrical connectivity. This view enables you to see a
physical bird's eye view of the installation site showing which panels
are connected in each string, which strings are connected to each
inverter and so on.
This window enables you to:

View the latest performance of specific components.

Find underperforming components, such as panels, by comparing their
performance to that of other components of the same type.

Pinpoint the location of alerted components.

See how components are connected to each other.
In order to enable the SolarEdge Monitoring Portal to show the strings and
physical location of power optimizers, you may first report the physical and
logical mapping of the installed power optimizers by mail, email or fax to
SolarEdge. SolarEdge will then upload this information to the SolarEdge
Monitoring Server.
IMPORTANT NOTE:
Even if you do not report the physical and logical mapping of the installed power
optimizers to SolarEdge, the SolarEdge Monitoring Portal will still show the logical
layout indicating which power optimizers are connected to which inverters. However,
it will not show strings or the physical location of power optimizers.
This process prepares the SolarEdge Monitoring Portal for receiving
up-to-date information from the installation site and for displaying it in a
physical or logical view.
