Page 1 RTR-5W User s Manual Thank you for purchasing our product. Carefully read this instruction manual- before using this unit. © Copyright T&D Corporation. All rights reserved. 2010.08 16507020004 9th Edition (US)
Page 2 ■ Notices about using this User's Manual In order to properly use this product, please carefully read this manual before using. T&D Corporation accepts no responsibility for any malfunction of and/or trouble with this product or with your computer that is caused by the improper handling of this product and will deem such trouble or malfunction as falling outside the conditions for free repair outlined in the attached warranty.
Page 3: Software User's Agreement
- T&D Corporation shall not accept any responsibility for any damage whether direct or indirect that results from the usage of RTR-5W for Windows. - Speciﬁcations of RTR-5W for Windows may be subject to change and service may be terminated without advance notice to the user. In such a case, T&D Corporation shall not be responsible for any damages, whether direct or indirect, from the inability to use RTR-5W for Windows.
Page 4: Safety Precautions And Instructions
Safety Precautions and Instructions To ensure safety be sure to obey all of the following warnings. The following items should be strictly obeyed for the safe usage of this unit, and for protecting yourself and other people from bodily harm and/or damage to property. Before using make sure to carefully read, understand and follow the safety rules and precautions for our products as outlined below.
Page 5 Warning Do not take apart, repair or modify the main unit. This may cause ﬁre or electrocution. When installing and using this product, make sure to follow all warnings and directions from your computer manufacturer. Be careful of igniting ﬁre. If water or a foreign body enters into this unit, immediately unplug the AC adaptor and stop using.
Page 6 Caution We are not responsible for any damage, malfunction or trouble, whether direct or indirect, caused by the use of our product. Please be fully aware of this before using our product. This product has been designed for private or industrial use only. It is not for use in situations where strict safety precautions are necessary such as in connection with medical equipment, whether directly or indirectly.
Page 7 Do not use or store the unit in places such as listed below: Doing so may cause electrocution, ﬁre and/or other adverse effects to the device and/or your computer. - Areas exposed to direct sunlight This will cause the inside of the device to become overheated and may cause ﬁre, deformation, and/or other damage including malfunction.
Page 8: Table Of Contents
■ Connect the supplied LAN cable-------------------------------- 16 ■ Registering a Remote Unit --------------------------------------- 48 Communicating with the Data Logger ------------- 17 ■ Sending Registration Info to an RTR-5W -------------------- 49 ■ Communicating with a Data Logger via Optical ■ Wireless Communication Test ----------------------------------- 50...
Page 9 ■ Copying Display to Clipboard : From the [Tools] Menu ---- 78 Adjustment----------------------------------------------- 119 Operating the Graph Display ------------------------- 79 How to use the RTR-5W Web Viewer ------------- 122 ■ Returning to Original Size ---------------------------------------- 79 ■ Opening the RTR-5W Web Viewer ---------------------------- 122 ■...
Page 10: What Is Web Wing Wl Rtr-5W
(such as a router) and must ﬁrst make necessary arrangements with a provider for a line and get a ﬁxed IP address, domain, etc. * When making settings in an RTR-5W without any settings already made (when purchased or after resetting), it is necessary to carry out these settings using a wired LAN connection.
Page 11: Basic Functions
Connect to a Wireless LAN via CF Card The RTR-5W is designed with a CF card slot. By inserting a wireless LAN card in this CF card slot, it is possible to connect to a Wireless LAN; releasing you from the burden of cables and wiring.
Page 12: Basic Functions Of Rtr-5W For Windows
The software is made up of the following 5 applications: [Network Settings Utility], [RTR- 5W for Windows], [Temperature / Humidity Graph], [Multi-Scale Graph] and [Event Viewer]. Also, by using your web browser to access RTR-5W, it is possible to view data via the Internet.
Page 13 Temperature / Humidity Graph / Multi-Scale Graph Temperature and Humidity are displayed in the Temperature and Humidity Graph. In the Multi-Scale Graph, voltage, pulse, temperature and humidity data can be viewed in graph form. In Multi-Scale Graph, it is possible to make settings for scale and unit of measurement to match the type of data being downloaded.
Page 14 Use your browser to monitor current readings and view data graphs. - Monitor Current Readings The RTR-5W communicates with Remote Units at a set regular interval and then stores the gathered readings. The most recent measurement will be displayed. It is also possible to view via a cell phone browser.
Page 15: Package Contents
Package Contents The following items are included in the package: Web Wing WL RTR-5W Software CD-ROM x 1 x 1 unit LAN Cable LN-20W x 1 AC Adaptor AD-0605 x 1 �� ...
Page 16: Rtr-5W Part Names And Functions
RTR-5W Part Names and Functions ■ Part Names FRONT POWER Optical Communication Area Alarm Monitor POWER LED While the power is ON, the lamp will be on. Alarm LED When a warning occurs, the lamp will blink. While wireless communication is occurring with a Remote Unit, Monitor LED the lamp will blink.
Page 17 Do not insert or try to connect anything other than a CF communication card. RESET Button Press to return to the factory default settings. *For more about Wireless LAN connections please refer to: FAQ's >> Q&A about RTR-5W >> Q.6 “I want to use a wireless LAN… "(p.137)
Page 18: Before Using
Before Using... *When using an RTR-50 as a Repeater Thank you for purchasing this product. Please be careful about the procedures for Installation. (For USB communication between your computer and an RTR-50) The application and USB device driver must be installed for USB communication between your computer and an RTR-50.
Page 19: Outline Of Use
5. Install RTR-5W for Windows To enable set up, install the supplied software RTR-5W for Windows into your computer. By installing RTR-5W, all of the following applications will be installed: [RTR-5W for Windows] for setting up Remote Units, making recording settings and other operational settings, [Network Settings Utility] for making network settings, and [Temperature / Humidity Graph], [Multi-Scale Graph], [Event Viewer] for viewing various types of recorded data.
Page 20 [IP address] and [Subnet Mask]. More detailed settings can be made in [Detailed Network Settings]. 2. Remote Unit Registration... from RTR-5W for Windows In order to carry out wireless communication between an RTR-5W base station and a Remote Unit, please register Data Loggers as Remote Units as follows. 1. Create a Location 2.
Page 21 Graph Display Temp / Humidity Graph Temperature and Humidity data can be displayed in the same Temperature / Humidity Graph (Up to 8 channels of data). You can view the data displayed in the graph window as a list and also choose to print. It is also possible to convert the data to common text ﬁle format (CSV type format).
Page 22 The downloading of data can be set to be automatically carried out at a speciﬁed time or at a set interval of time. For Auto download to occur at a set time, it is necessary for RTR-5W for Windows to be open. Gather Current Data... from RTR-5W for Windows RTR-5W communicates with Remote Units to gather and display the current measurement readings.
Page 23: Software Operations Table
■ Software Operations Table RTR-5W for Windows Open Temp/Humidity Graph Open Multi-scale Graph [File] Open Event Viewer menu Text Data Output Settings Read Data Collector Registration Info File Output Registration Info File for Data Collector Expand to Whole Tree Programmed Auto Download...
Page 24 IP Block Detailed Wireless LAN Settings Port Number Time Difference Mail Auth Settings Rebooting the Communication Functions (Restarting the System) Login History – ON / OFF [Menu] Clear Login History Menu Communication Time Settings RTR-5W Web Viewer Monitor Current Readings Graph...
Page 25: Getting The Rtr-5W Ready To Use
Getting the RTR-5W Ready to Use ■ Connect the supplied AC adaptor *To ensure a proper connection make sure that the plug is completely inserted NOTE: - Do not use an AC adaptor other than the one that is supplied with the product. Doing so may cause ﬁre or other trouble.
Page 26: Communicating With The Data Logger
■ Communicating with a Data Logger via Optical Communication Optical communication can be carried out by placing an RTR-51/52/52Pt/53, RVR-52A Data Logger face down on the RTR-5W so that the optical communication areas meet. *To make measuring mode changes in an RVR-52A, use via optical communication when registering a Remote Unit.
Page 27: External Output
External Output ■ Connecting the Signal Wire Prepare a Φ 0.5 to 0.9 single type wire and remove the covering to about 10mm from the tip. Using a screwdriver or other such tools, while pressing down on the <terminal Button B> at the back of the unit, insert the wire into the <hole A>. ◆...
Page 28: Checking Your Operating Environment
Please use a Wireless LAN card and a Wireless LAN access point (Combined Wireless LAN and Hub OK). *For more about Wireless LAN connections please refer to: FAQ’s >> Q&A about RTR-5W >> Q.6 “I want to use a wireless LAN… “(p.137) ■...
Page 29: Connecting To A Network
Connecting to a Network The following are some ways to connect an RTR-5W to a network. Please select the connection method that suits your network environment. ■ Connecting to a HUB for in-company Communication *To ensure a proper connection make sure that the plug is completely inserted.
Page 30: Connecting To A Wireless Lan
■ Connecting to a Wireless LAN By inserting a Wireless LAN card into the RTR-5W, it is possible to carry out communication in places where LAN wiring is difﬁcult or troublesome. *To ensure a proper connection make sure that the wireless LAN card is completely inserted.
Page 31: Connecting To The Internet
Connection Example ■ Using the RTR-5W on the Internet In order to access the RTR-5W from your browser, enter the Global IP address that has been assigned to the RTR-5W in your browser's URL bar following [http://] The RTR-5W will be called via a router or the Internet provider.
Page 32 SMTP server (for sending) and a POP or IMAP server (for receiving) in the network. ■ Sending Internet Mail ① The RTR-5W, via a router or provider, accesses an SMTP server that exists on the Internet and sends mail to the SMTP server.
Page 33: Installation
Installation Install the provided software. - Is Windows operating properly? If Windows is not operating properly, RTR-5W for Windows may not be installed correctly or it may not operate properly. - Please quit all other applications. If other programs are open, please close and quit all of them, making sure to quit all Quick Start programs such as a virus checker.
Page 34 Select [Install RTR-5W for Windows] and click the [Execute] Button to start the installation. Continue the installation by following the directions as they appear. After installation has been completed, [RTR-5W for Windows] will be registered in the Window's [Start] Menu.
Page 35 Conﬁrming the contents as you go, install the software according to the directions. After the application has been installed, the following message will appear. Click the [Install ] Button. [Install] Button *After installation is completed, an icon for [RTR-5W for Windows] will appear in the Start Menu.
Page 36: Using The Network Settings Utility
Using the Network Settings Utility ■ How to Open From the list of programs in the Window's Start Menu, click on [RTR-5W for Windows] - [Network Settings Utility]. ■ Using Help For details about how to use the software, please see the explanations in the Software Help Menu.
Page 37: Network Settings Utility Functions
The reception of RTR-5W settings and more detailed network settings can be made here. In the SNTP settings, it is possible to make settings so that the RTR-5W clock settings can be automatically received from NTP server. Clock settings can be made directly using [RTR- 5W for Windows] software, but if an RTR-5W is rebooted (restarted) the clock settings will be initialized.
Page 38: Network Initialization Settings
NOTE: Please note, that upon purchase, all RTR-5W units are set with the same IP address. To make IP address changes, connect one unit at a time and carry out the changes. Do not connect more than one unit with the same address to the network at the same time.
Page 39 Button After entering the above, next, enter the Login ID and Password. The RTR-5W factory default Login ID is "wsc-user" and the Password is "wsc-passwd". Make any necessary changes to the Login ID and Password in the [Detailed Network Settings]. See p.31-34 for details.
Page 40: Detailed Network Settings
After making the network initialization settings for the RTR-5W, the reception of RTR-5W settings and more detailed network settings can be made. *Before making any of these settings, please make sure that the RTR-5W is set with the proper IP address.
Page 41: Making Settings (Changes)
[Send Settings] Button. A message will appear asking you if it is OK to restart the system. Click the [Yes] Button to restart. *The new settings will not become valid until the RTR-5W communication function is restarted. [Yes] Button...
Page 42 [Mail Auth Settings] Button In order to send warning report mails from the RTR-5W, it is necessary to make the following settings if you are using an SMTP server that requires SMTP authentication or POP before SMTP. In the [Detailed Network Settings] window, click the [Mail Auth Settings] Button and make any necessary settings changes.
Page 43 If the browser does not open, wireless communication continually results in failure, or if any errors occur during communication, click the [Re-activate Communication] Button. Note that by restarting, the data transfer graph in the RTR-5W Web Viewer will also be reset.
Page 44: Returning The Network Settings To The Factory
If you have forgotten the IP address or the password you can easily return the logger to the default factory settings. Pull out the AC adaptor plug from the RTR-5W logger. Press in the [RESET] Button on the RTR-5W logger with a pointed object and reconnect the AC adaptor. [RESET] Button...
Page 45: Rtr-5W Clock Settings
RTR-5W Clock Settings If the clock settings for the RTR-5W are not set correctly, the clock in the RTR-5W Web Viewer and the time of warnings will also be incorrect. Please make sure to set correctly before beginning to use.
Page 46 Enter the information for the recipient A message will appear asking you if it is OK to restart the system. Click the [Yes] Button to restart. *The new settings will not become valid until the RTR-5W communication function is restarted. [Yes] Button After restarting has ﬁnished, the settings will have been completed.
Page 47: Making The Clock Settings Manually
If you wish to directly enter a speciﬁed date and time, select [Set using the Computer clock settings] and enter the desired settings. [Set] Button Click the [Set] Button to send the settings to the RTR-5W and complete the settings.
Page 48: How To Operate Rtr-5W For Windows
How to Operate RTR-5W for Windows ■ How to Open From the list of programs in the Window's Start Menu, click on [RTR-5W for Windows] - [RTR-5W for Windows] to open. ■ Using Help For details about how to use the software, please see the explanations in the Software Help Menu.
Page 49: Rtr-5W For Windows Functions
RTR-5W for Windows is designed to allow the user to utilize RTR-51/52/52Pt/53, RVR-52A Data Loggers via the RTR-5W Base Station. From the main window it is possible to carry out the various tasks such as Registrations, Recording and Warning Monitoring Settings, as well as the Downloading of Data.
Page 50: Remote Unit / Repeater Installation Procedures
Remote Unit / Repeater Installation Procedures Connect the provided AC adaptor to the Base Unit (RTR-5W), and connect the LAN cable to the PC For more details see "p.16 Getting the RTR-5W Ready to Use". Register Groups and Remote Units Register all Remote Units to be placed.
Page 51: About Repeaters
■ About Repeaters A "Repeater" is deﬁned as an RTR-50 Wireless Communication Port that has been registered as a "Repeater" to act as a relay for Wireless Communication between a Base Unit and Remote Units from the our RTR-5 Series. [Limitations when using a Repeater] Although it is logically possible to register up to 250 Repeaters in a route, each additional Repeater added to the route will proportionately increase communication time.
Page 52 NOTE: It is possible to set up so that more than one Repeater acts as a relay for the same Remote Units. However because wireless communication is carried out in Groups of Remote Units, the same Group will be relayed through different Repeaters causing inefﬁciency and an increase in the amount of communication time to more than necessary.
Page 53: Remote Registration
Remote Registration In order to carry out Wireless Communication between a Data Logger and an RTR-5W Base Station, it is ﬁrst necessary to register the Data Logger as a Remote Unit of that RTR-5W. ■ Creating a Location Open [RTR-5W for Windows].
Page 54 Time Setting] Access Settings [Send Daylight Saving Time Info to RTR-5W]Button Enter the IP address (or Domain) for the RTR-5W that was entered in the [Network Settings Utility]. Browser Display Settings If necessary, make settings in the [Browser Display Settings] Area.
Page 55 NOTE: About the Rebooting of an RTR-5W - By rebooting an RTR-5W, the unit’s internal clock will automatically return to its default settings. If SNTP settings have not been made, please make sure to reset the internal clock to your current local time before using.
Page 56: Creating Groups
■ Creating Groups In the [Registration / Administration] Menu, click on [Create Group] to display a window where you can enter a name for the new Group. *Up to 8 characters can be entered. *In the Location name, you cannot use a space, or any of the following characters [\/:,;*?"<>|&].
Page 57: Registering A Remote Unit
Click the [OK] Button to ﬁnish the Group settings. ■ Registering a Remote Unit Place a Data Logger face down on the RTR-5W. -See p.17 for more details about how to connect. Select the Group in which you wish to register Remote Units from the Administration Tree.
Page 58: Sending Registration Info To An Rtr-5W
Select a Location from the Administration Tree, and in the [Settings] Menu, select [Send Group / Remote Info]. [Send] Button Click the [Send] Button to send the registration info to the RTR-5W and complete the settings. *Make sure to carry out this operation each time changes are made to settings.
Page 59: Wireless Communication Test
If no Repeaters exist, gather the current data readings from each Remote Unit and check to make sure that wireless communication is possible between the Remote Units and the RTR-5W Station. Place a Remote Unit in the actual place from which you wish to measure and record data.
Page 60: Repeater Registration
For Windows 2000 / Vista / 7 When installing the software " RTR-5W for Windows " , the USB Device Driver will also be installed automatically. Checking the USB Device Driver Installation... For Windows Vista / 7 Connect the RTR-50 (Repeater) to the Computer with a USB cable.
Page 61 Checking the USB Device Driver Installation... For Windows 2000 Connect the RTR-50 (Repeater) to the Computer with a USB cable. For how to connect to a computer, see the User ' s Manual that accompanies your RTR-50 Wireless Communication Port. Open the [Control Panel] and double click on [System];...
Page 62: Installing The Usb Device Driver
■ Installing the USB Device Driver To install " RTR-5W for Windows " , it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it. For Windows XP Before installing the USB device driver, make sure to install the software " RTR-5W for Windows "...
Page 63 After completing installation, click the [Finish] Button. If the driver is not automatically detected Follow the directions below to install. Disconnect the USB cable from the Data Collector and then re-connect it. The [Add New Hardware Wizard] will automatically open. - If a window appears such as the one below, check [No, not this time] and then click the [Next] Button.
Page 64 Button [Next] Button - Select the driver for the device being used from the folder where [RTR-5W for Windows] was installed. ・For RTR-50... RTR-5W for Windows\Driver RTR-50 - Insert the CD-ROM into the proper drive and from the CD-ROM select the driver for the device being used.
Page 65 Checking the USB Device Driver Installation... For Windows XP Connect the RTR-50 (Repeater) to the Computer with a USB cable. For how to connect to a computer, see the User ' s Manual that accompanies your RTR-50 Wireless Communication Port. From the [Control Panel], click on [Performance and Maintenance] - [System];...
Page 66: Registering A Repeater
NOTE : Application version 1.40 is not compatible for USB communication with Windows Vista / 7 OS. Open [RTR-5W for Windows]. In the [Registration / Administration] Menu, click on [Repeater Registration] to display a window which shows a list of the current Registration contents.
Page 67 Com. Fre. Ch - Here it is possible to set the frequency channel for when registering the new Relay Route name. - The "Relay Route Frequency Channel" is the channel used for the communication among Repeaters and is different from the term "Frequency Channel" which means the channel used for the communication between the Base and Remote Units.
Page 68: Assigning Remote Units To A Repeater
■ Assigning Remote Units to a Repeater From the current Registration contents, select the Remote Units that you wish to assign to a Repeater; by right clicking a menu will appear. Registration List By clicking "Assigning Remote Units to a Repeaters", a display will appear in which you can select the Repeater.
Page 69 Removing a Remote Unit from a Relay Route From the Registration List, select the Remote Units which you wish to remove from the Relay Route. By right clicking a menu will appear; select "Use No Relay" and the Remote will move to be directly under the Base Unit.
Page 70 - Results: Displays whether the connected unit has been Initialized or registered as a "Repeater" *The Initialized setting is as a Base Unit for another T&D product. *In the RTR-5W system this can only be used as a Repeater. - Relay Route Name: the Relay Route Name will appear.
Page 71: Wireless Communication Test
■ Wireless Communication Test In the [Repeater Registration] window, select [Communication] - [Wireless Communication Test]. Select the Search method and click [Start Communication] to begin. [Start Communication] Button Test All Remote and Repeaters This will test and gather signal strength to all Remote Units listed in the Registration List via all Repeaters as they are set up as well as all Remote Units that communicate directly with the Base Unit.
Page 72 The Communication Test results will appear. Communication Successful The number of vertical lines shows the Radio Wave Strength. (Min: 1 / Max: 5) If testing is of a Repeater, the Radio Wave Strength shown will be for between that Unit and the Unit with one number before it. (If the Repeater Number is 1 then the Strength shown will be for communication with the Base Unit).
Page 73: Recording Settings
- When using RTR-52Pt, please makes sure to carry out sensor settings as detailed in "RTR-52Pt Sensor Settings" on p.118. Open [RTR-5W for Windows]. From the Administration Tree, select the Remote Unit for which you wish to make recording settings, and in the [Settings] Menu, select [Start / Stop Recording].
Page 74 Unit of Temperature for Display: [Select from: Celsius or Fahrenheit] for RTR-51/52/53 Here you can shift the unit of display between Celsius (ºC) and Fahrenheit (ºF). * When using Fahrenheit in the RTR-52Pt LCD, the Logger can only show between -199.9 and 999.9 ﾟ...
Page 75: Measuring Moisture (Rvr-52A)
Click the [Start Recording] Button to send the recording condition settings via the RTR-5W Base Station to the Remote Unit and complete the set-up. NOTE: By starting a new recording session, all currently recorded data will be erased. [Get Settings] Button Gather current recording condition settings from the selected Remote Unit.
Page 76: Downloading Data
■ When using Wireless Communication Open [RTR-5W for Windows]. From the Administration Tree, select the Remote Unit from which you wish to download data, and in the [Data] Menu, select [Download Data].
Page 77: When Using Optical Communication
■ When using Optical Communication Open [RTR-5W for Windows]. Place the Remote Unit from which you wish to download data face down on top of the speciﬁed RTR-5W (Location). From the Administration Tree, select the Location you will use for Optical Communication.
Page 78: Operating The Temp / Humidity Graph
Operating the Temp / Humidity Graph ■ How to Open From the list of programs in the Window's Start Menu, click on [RTR-5W for Windows] - [Temp / Humidity Graph]. ■ Using Help For details about how to use the software, please see the explanations in the Software Help Menu.
Page 79: Temperature / Humidity Graph Display Names And Functions
■ Temperature / Humidity Graph Display Names and Functions ⑤ ⑥ ⑤ ④ ③ ⑦ ⑧ ⑦ ① ① ⑨ ⑩...
Page 80 Zoom in Using the Mouse With the left button drag the mouse to outline the area you want to zoom in on. Menu Display Using the Mouse By right clicking on the graph, the Menu will be displayed. Display Graph Using Drag and Drop It is possible to view data in graph form by dragging a recorded data ﬁle and dropping it onto the Graph.
Page 81: Data List Display Part Names And Functions
■ Data List Display Part Names and Functions This is the list of data being displayed in the Graph window.(Open from [View] Menu.) [Date/Time] Button By clicking this button, you can shift the display between the recorded date and the amount of elapsed time since recording started.
Page 82: Making Changes To The Graph Display
Making Changes to the Graph Display ■ Changing Colors of Data Display Area: From the [View] Menu You can change the letters used in the data list display for each channel between monochrome and channel color. ■ Selected Channels ON / OFF : From the [View] Menu You can choose to view only the selected channels in the Graph.
Page 83: Editing Recording Conditions: From The [Tools] Menu
■ Editing Recording Conditions: From the [Tools] Menu It is possible to make corrections to channel names and to recording start date and times. By clicking the [Channel No.] Button of the channel you wish to edit, the [Name] and [Started Date / Time] in the "Edit Items" display will show info for that channel number.
Page 84: Re-Ordering Channel Data: From The [Tools] Menu
■ Re-ordering Channel Data: From the [Tools] Menu You can re-order the data during graph display. There are two methods to use when re-ordering channels: [Re-order by Dragging a Channel Number] and [Specify the Channel Numbers to be Moved]. 【Re-order by Dragging a Channel Number】 Drag the channel number you wish to move to the newly desired channel number position and drop it.
Page 85: Erasing Selected Channel Data : From The [Tools] Menu
■ Erasing Selected Channel Data : From the [Tools] Menu Put a check on the channel number you wish to erase. By clicking on the [OK] Button, the deletion will be completed. [OK] Button Check Shifting Unit (ºC /ºF) : From the [Tools] Menu By clicking on [Shift Unit (ºC /ºF)], you can automatically change the temperature unit scale in the graph display and in the channel info list.
Page 86: Changing Graph Colors : From The [Tools] Menu
■ Changing Graph Colors : From the [Tools] Menu Click the channel number of which you wish to change the color. You can change the colors of the channel name, graph background, the scale lines, the enlarged box area, and the AB cursors. Color sample...
Page 87: Copying Display To Clipboard : From The [Tools] Menu
■ Copying Display to Clipboard : From the [Tools] Menu By clicking [Copy Display to Clipboard], you can copy the currently displayed window to the clipboard and make use of the graph by pasting to other software.
Page 88: Operating The Graph Display
Operating the Graph Display ■ Returning to Original Size Clicking here will return the graph to its original size. ■ Zooming In and Out Zooms in or out one step at a time ■ Moving the A/B Cursors Right and Left Simultaneously move the AB Cursors to the right or left.
Page 89: How To Operate The Multi-Scale Graph
How to operate the Multi-scale Graph ■ How to Open From the list of programs in the Windows Start Menu, click on [RTR-5W for Windows] - [Multi-scale Graph]. ■ Using Help For details about how to use the software, please see the explanations in the Software Help Menu.
Page 90: Multi-Scale Graph Display Names And Functions
■ Multi-scale Graph Display Names and Functions ⑥ ⑦ ⑧ ⑥ ⑤ ④ ⑨ ③ ⑩ ② ⑨ ① ⑪ ⑫ A and B Cursor Movement Buttons By clicking the arrow buttons, you can simultaneously move the A/B cursors. A and B Cursor Buttons Click and drag the A or B button to move the cursor to the left or right.
Page 91 Zoom in Using the Mouse With the left button drag the mouse to outline the area you want to zoom in on. Menu Display Using the Mouse By right clicking on the graph, the Menu will be displayed. Display Graph Using Drag and Drop It is possible to view data in graph form by dragging a recorded data ﬁle and dropping it onto the Graph.
Page 92: Data List Display Part Names And Functions
■ Data List Display Part Names and Functions This is a list of the data that was displayed in graph form. From the [View] Menu [Date / Time] Button: By clicking this button, you can shift the display between the recorded date and the amount of elapsed time since recording started.
Page 93: Making Changes To The Graph Display
Making Changes to the Graph Display ■ Selected Channels ON / OFF : From the [View] Menu You can choose to view only the selected channels in the Graph. By moving the mouse to [Selected Channels ON / OFF], the channel numbers are displayed.
Page 94: Setting High, Low, Average Calculation Range: From The [Tools] Menu85
■ Setting High, Low, Average Calculation Range: From the [Tools] Menu Enter a calculation range in the [New Calculation Range]. [OK] Button [Entire Graph] Button Enter the numerical values - By clicking the [Entire Graph] Button, the dates and times for the entire graph will be displayed.
Page 95: Editing Recording Conditions: From The [Tools] Menu
■ Editing Recording Conditions: From the [Tools] Menu It is possible to make corrections to channel names and to recording start date and times. By clicking the [Channel No.] Button of the channel you wish to edit, the [Name] and [Started Date / Time] in the "Edit Items" display will show info for that channel number.
Page 96: Re-Ordering Channel Data: From The [Tools] Menu
■ Re-ordering Channel Data: From the [Tools] Menu You can re-order the data during graph display. There are two methods to use when re-ordering channels: [Re-order by Dragging a Channel Number] and [Specify the Channel Numbers to be Moved]. 【Re-order by Dragging a Channel Number】 Drag the channel name / number you wish to move to the newly desired channel name / number position and drop it.
Page 97: Merging Channel Data: From [Tools] Menu
■ Merging Channel Data: From [Tools] Menu It is possible to merge two different pieces of data into one piece of data. NOTE: - The following data cannot be merged - If the total number of readings after merging exceeds 16,000 data readings. - If the recording intervals are different - If the data is of different types - If the conversion equation for the scale settings are different...
Page 98: Erasing Selected Channel Data : From The [Tools] Menu
■ Erasing Selected Channel Data : From the [Tools] Menu Put a check on the channel number you wish to erase. Click the [OK] Button to complete the deletion. [OK] Button Check...
Page 99: Setting Vertical Axis Display Range: From The [Tools] Menu
■ Setting Vertical Axis Display Range: From the [Tools] Menu It is possible to set the upper and lower values of the vertical axis scale for each channel. NOTE: - In this case, the data graph lines may under certain circumstances stick out of the graph. - Settings for the upper limit must be 40.000 or lower and settings for the lower limit must be -40.000 or higher.
Page 100: Scale / Unit Conversion: From [Tools] Menu
■ Scale / Unit Conversion: From [Tools] Menu It is possible to make settings for the conversion of units and scales for each channel of downloaded data. Select to use 2 voltage points to convert the scale, [Designate by 2 points] or to use the conversion equation of [Designate by y=Ax+B].
Page 101: Changing Graph Colors : From The [Tools] Menu
■ Changing Graph Colors : From the [Tools] Menu Click the channel number or item for which you wish to make changes. If you wish to change the color: click the appropriate Button to view the color selection samples. If you wish to change the type of line: click the [Line Type] Button to view the line type selections.
Page 102 After conﬁrming the color in the image preview display, click the [Close] Button to complete the changes. *By clicking the [Default] Button, you will return to the color settings to the Default settings. Memo Here it is possible to save one pattern of settings for use in the display and one for use when printing.
Page 103: Operating The Graph Display
Operating the Graph Display ■ Returning to Original Size Return from zooming in on one part of data to the original whole graph size. ■ Zooming out step by step Return by regular steps from zooming in on one part of data to show larger ranges of data.
Page 104: Event Viewer
How to Operate the Event Viewer ■ How to Open From the list of programs in the Window's Start Menu, click on [RTR-5W for Windows] - [Event Viewer]. ■ Using Help For details about how to use the software, please see the explanations in the Software Help Menu.
Page 105: Event Viewer Display Part Names And Functions
■ Event Viewer Display Part Names and Functions With Event Viewer you can view Recorded Event Time Data in a List (up to 64 channels), Print the List, or Save as Text File. ② ③ ① ④ ⑤ ① Menu Bar Menus are lined up which contain various commands.
Page 106: Changing The Event Viewer Method Of Display
Changing the Event Viewer Method of Display ■ Shifting Display: From the [View] Menu or the Toolbar You can shift the display to view either by the recorded date / time or by the elapsed time from the last recorded data. Recorded Date/ Time Display Elapsed Time...
Page 107: File Info: From The [View] Menu
■ File Info: From the [View] Menu View ﬁle info about data in the currently displayed data list. File Name: File names of the data ﬁles currently displayed in the data list. Path: The Location where the File is saved Date Created: The date and time when the data ﬁle was created.
Page 108: Print Preview And Printing
Print Preview and Printing Preview only that data which was selected and print. In the [File] Menu, select [Print Preview and Print]. In the [Select Channel for Printing] File list, select the channels you wish to print and click the [OK] Button. [OK] Button The [Print Preview] will be displayed.
Page 109: Saving Recorded Data
Saving Recorded Data If you have edited any data that was displayed in a graph, we suggest that you save it as necessary. 3 Ways to Save Files *In “Event Viewer” only [Save Data as…] can be used. -In the [File] Menu, select [Overwrite All Data] Will save any changes to ﬁle without changing File Name and Saving Location.
Page 110: Creating Text File
Creating Text File By saving the recorded data as text ﬁle, you can create a ﬁle type that can be read by common spreadsheet software. Click [Save in Text File] in the [File] Menu. Select the [Text File Type] and [Range to be Saved], and click [OK]. - Comma, Tab, Space, and Semi-colon are codes used by common spreadsheet ®...
Page 111 For Event Viewer In the [File] Menu, click [Save in Text File]. Select the [Text File Type], click [Designate File] Button and specify the saving location. *Comma, Tab, Space, and Semi-colon are codes used by common spreadsheet ® ® software, such as Excel and Lotus , when reading Text File to divide cells.
Page 112: Opening A Saved File
Opening a Saved File To open a previously saved ﬁle, designate the ﬁle name to open it. Click [Open] in the [File] Menu of the Graph Display. Select the name of the data you wish to open and click [Open] to view the data in graph form.
Page 113 *Using “RTR-5W for Windows” with Windows Vista or Windows 7 Note that, when using Windows Vista or Windows 7, if, as a normal User, “RTR-5W for Windows” was installed into the default folder [Program Files] the “Virtual Store” function may redirect and save ﬁles into separate folders for each User Account, as shown below: [C:\User\(AccountName)\AppData\Local\VirtualStore\Program Files\(Application)].
Page 114: Auto-Download Settings
Make settings here to automatically download data from the selected Remote Units at the speciﬁed time. Open [RTR-5W for Windows]. Select the Remote Unit(s) you wish to make settings for, and in the [Registration / Administration] Menu click on [Remote Unit Properties].
Page 115 Click the [OK] Button to ﬁnish the setting process. NOTE: - Make sure that RTR-5W for Windows is open when a programmed Auto-Download is scheduled to occur. - If another type of communication, such as a warning monitoring, occurs at the scheduled downloading time and downloading is not possible, downloading will begin upon the ending of the other communication.
Page 116 If you wish to Stop the Auto Downloading Select the Remote Unit(s) for which you wish to stop downloading, under the Auto Downloading settings put a check next to [Not to be carried out], and click the [OK] Button. Programmed Auto Download: From [View] – [Programmed Auto Download] If a Remote Unit is set for Auto Download, this will show the time of the next scheduled download.
Page 117 (all displays are taken from Vista) To solve this problem please take steps such as the following: Place a shortcut for “RTR-5W for Windows” in the “Startup” Folder of the “Start” Menu. By doing this,“RTR-5W for Windows” will be started when Windows is restarted, and...
Page 118 In the "Change Settings" display, we do not recommend that the setting be for other than "Install updates automatically (recommended)". Therefore we suggest the following to disable the Auto-restart of your computer system after an installation has occurred. Windows Update – Change Settings Display * If in this display, the setting "Install updates automatically (recommended)"...
Page 119 4. Select "Enable" and click the [OK] Button or the [Apply] Button. By doing this the Auto-restart of the system will be stopped from occurring. 5. After ﬁnishing the settings, downloads and the installation of repair programs from Windows Update will occur automatically, but while being logged on, Auto-restart of the system will not occur.
Page 120: Warning Monitoring
Server Name" in [Warning Mail]. Enter the DNS server address Enter SMTP settings Open [RTR-5W for Windows]. Select the Remote Unit(s) you wish to make settings for, and in the [Registration /Administration] Menu click on [Remote Unit Properties]. *By right clicking on the selected Remote Unit icon(s), a popup menu will appear where you can select [Remote Unit Properties] to display the same window.
Page 121 In the [Settings] Menu, click on [Start / Stop Warning]. *By right clicking on the selected Remote Unit icon(s), a popup menu will appear where you can select [Start / Stop Warning] to display the same window. [Warning Monitoring] [notiﬁcation address] [A sender address] [Notiﬁcation Settings] Make the desired settings.
Page 122 Place a check here if you wish to have an alarm or warning lamp that is connected to the external output go on when a warning occurs. Click the [Set] Button to send the settings info to the RTR-5W and complete the settings.
Page 123 [Notiﬁcation Test] Button Use this to send a test mail from the RTR-5W to the notiﬁcation address and conﬁrm that the warning notiﬁcation settings are correct. A notiﬁcation test is successful if a notiﬁcation test mail reaches the notiﬁcation address.
Page 124: Battery Life Warning Settings
Battery Life Warning Settings Make settings here to send a notiﬁcation of low battery power via e-mail from the RTR-5W. Open RTR-5W for Windows. Click on [Remote Unit Battery Life Warning Settings] in the [Settings] Menu. Place a check next to [Send Warning E-mail from RTR-5W] and enter the Send Time, Sender Address and Recipient Address.
Page 125: Mail Settings For Download
"Multi-Scale Graph" and "RP7" can be opened by "Event Viewer" (These ﬁle formats are the same as the ﬁle formats which are created when downloading data using "RTR-5W for Windows".) - Binary Format (for open format): By using this public format, users can create their own...
Page 126 This will retrieve download schedule info from the RTR-5W and display the time of the next scheduled download. NOTE: New settings made here will not be transmitted to the RTR-5W and will not become activated until the [OK] Button has been clicked.
Page 127: Rtr-52Pt Sensor Settings
Place a check next to [Pt100] or [Pt1000] and click the [Send] Button to send the settings and complete set-up. [Get Sensor Type] Button The sensor settings for the RTR-52Pt unit currently placed on top of the RTR-5W will be gathered.
Page 128: Adjustment
Open [RTR-5W for Windows]. From the Administration Tree, select the Remote Unit (only one at a time) for which settings are to be made and place it face down on top of the RTR-5W. In the [Settings] Menu, select [Adjustment Settings (Optical Communication)].
Page 129 Check the Method of Adjustment: [1 Point Adjustment] or [2 Point Adjustment] . - 1-Point Adjustment: Use when measuring in a range of ± 20. - 2-Point Adjustment: Use when measuring in a wide range. [Initialize] Button [Send Settings] Button Check one Enter the actual pre-adjusted reading(s) in the "Current Reading"...
Page 130 1-Point Adjustment: Use when measuring in a range of ±２０℃ . This adjustment method changes only the offset (b) where the slope (a) is considered 1. For example, the Data Logger is measuring 10.2℃ , but the standard says the actual measurement should be 10℃...
Page 131: How To Use The Rtr-5W Web Viewer
Internet. *Make settings to enable both Java applets and JavaScript. In the address area, enter the address of the RTR-5W logger you wish to view. Enter Address By pressing the [Enter] key, the RTR-5W Web Viewer will appear.
Page 132: Rtr-5W Web Viewer Functions
Also, it is possible to view the Data Transfer Graph for the current readings. Monitor Current Readings The RTR-5W displays the newest measurement readings that are collected at the regular interval set in [Location (RTR-5W) Properties]. By clicking the [Gather Current Readings] Button, communication will begin with the RTR-5W and the current readings will be displayed.
Page 133: Current Readings Monitor (Accessing Via Browser)
- For details about how to make settings see part 4 [Browser Display Settings] of p.45 [Remote Registration]. Open the Web Viewer for the RTR-5W of which you wish to view the current readings. - See p.122 for more details about the display.
Page 134: Graph (Accessing Via Browser)
- For details about how to make settings see part 4 [Browser Display Settings] of p.45 [Remote Registration]. Open the Web Viewer for the RTR-5W of which you wish to view the Graph. - See p.122 for more details about the display.
Page 135: Viewing Current Readings Via Mobile Phone
The Current Readings display will automatically open. NOTE : - To view the current readings monitor via mobile phone, it is necessary to open the RTR-5W to the public on the Internet. - The current readings will not be automatically refreshed. You will have to use the browser refresh function on you cell phone.
Page 136: Checking And Making Changes To Computer Network Settings
Checking and Making Changes to Computer Network Settings For some network environments, it may be necessary to make changes to the IP address and subnet mask at the computer side in order to carry out a search. See the following procedures for checking and making changes to your computer network settings.
Page 137 Click the [OK] Button as seen in the 3 Properties window to close the window. Once again, in the [Network Settings Utility] run a search and check whether the IP address for the RTR-5W connected to the network is displayed.
Page 138 . If it is displayed properly, make the initial network settings. . After making the initial network settings, follow steps 1-4 above to open the [Internet Protocol (TCP / IP) Properties] window. Re-enter the [IP address], [Subnet mask], [Default Gateway], [Preferred DNS server], and [Alternate DNS server] that you had written down before and click the [OK] Button.
Page 139: If Usb Device Driver Installation Fails
If USB Device Driver Installation Fails If, during USB device driver installation, some trouble occurs that results in a failure to install properly, the following display will appear in the Device Manager. For Windows XP If this occurs, the USB device driver must be re-installed. ■...
Page 140 In the Device Manager Window, right click on [USB Device] under [Other Devices] and then click on [Properties] to display the [USB Device Properties] Window. In the USB Device Properties Window, click on the [Re-install Driver] Button to display the Hardware Detection Wizard. Follow the directions to install. [Re-install Driver] Button...
Page 141: Re-Installing
Re-installing Before reinstalling or updating the [RTR-5W for Windows] software, make sure to carry out the uninstall program ﬁrst. Also, before uninstalling, make sure to quit all [RTR-5W for Windows] applications. * To install [RTR-5W for Windows], it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it.
Page 142 For Windows Vista / 7 In the [Control Panel], click [Program – Program Uninstall]. From the list of currently installed programs, select [RTR-5W for Windows] and click the [Uninstall] Button. The [Install Shield Wizard] will appear. Check [Remove], and click [Next].
Page 143: Troubleshooting
One of the following may be the reason: Power is not being supplied by the AC adaptor to the RTR-5W. The RTR-5W and the computer you are using are not on the same network. The [Network Settings Utility] is already being used by another computer.
Page 144 Q.6 Because of some other [Communication Error] communication cannot occur. Why? One of the following may be the reason: - The IP Block setting is ON and communication can occur with only speciﬁc PC's. - If after several attempts a communication error continues to occur, turn OFF the RTR- 5W and restart.
Page 145: Q&A About Rtr-5W
The RTR-5W has an internal clock (calendar) built into it. If the internal clock settings for the RTR-5W are not set correctly, the date and time in the RTR-5W Web Viewer’s current readings monitor and the time of warnings will also be incorrect.
Page 146 Q.6 I want to use a wireless LAN; which products can I use? Currently, the only Wireless LAN card which has been tested and proven compatible with the RTR-5W is the Dark Marketing Corporation’s Wireless LAN card “XI-815”. Unfortunately, the production and sales of this card have been discontinued.If you already have this Wireless LAN card please use as directed.
Page 147: Q&A About Web Server Functions
Q.2 What must I do to view current RTR-5W readings on my cell phone? To view the current readings of a RTR-5W it is necessary to connect your cell phone to the Internet. If the RTR-5W is connected to the Internet it is possible to view the current readings via...
Page 148: Q&A About Networks
■ Q&A about Networks Q.1 What is a network? A network is a system in which a group of computers are connected by cable (copper wire, optical ﬁber, etc), infrared ray, radio waves or other means in order to share and exchange information.
Page 149 Q.4 How should I make settings for the IP address / Subnet mask? The IP address and Subnet mask settings vary depending upon your networking environment (structure). Please consult your network administrator for details. Below is a simpliﬁed explanation of a company LAN set up for your reference. If the computer connected to your company LAN has a Subnet mask of "255.255.255.0"...
Page 150 Q.8 What is a URL? A URL is an address that is written in a way so that it is easy for the DNS function to determine on which server the IP address is located. This address begins with "http:// " and is followed by such things as domain names, server names, port numbers, ﬁle names and other such info.
Page 151: Q&A About The Internet
If you are using only one RTR-5W connected to one router, then the ﬁxed IP address should not be set for the RTR-5W, but for the router. If you are using a multiple number of RTR- 5W connected to one router, the RTR-5W will use FTP and HTTP so, please set a ﬁxed IP address for each RTR-5W unit.
Page 152 Q.4 I want to use a URL without a ﬁxed IP address, how can I do that? If you wish to access an RTR-5W by URL but without a ﬁxed IP address, it is possible to use a dynamic DNS.
Page 153 Q.7 If I connect the RTR-5W to the Internet, is it not possible that another person could read my data or change my settings? Yes, as long as you are connected to the Internet, the logger could well be the target of unwanted access.
Page 154: Speciﬁcations
Special short wave radio wireless: 2000 readings per minute Optical Communication: 2400bps Communication Time When downloading data from Data Logger with RTR-5W via wireless communication (1 unit of full data takes about 420 seconds) External When operating the warning functionVoltage when OFF: AC/DC less than 50V / Current when Output(Warning Output) ON: less than 0.1A / ON Resistance: MAX 35 Ω...
Page 155: About The Rtr-5W Web Viewer
View Rising (Lo to Hi) Waves and Falling (Hi to Lo) Waves Other Functions Shift between Descending/Ascending File Output Special T&D Data File・Text File (CSV, etc) Printing Print Data List ■ About the RTR-5W Web Viewer Compatible devices RTR-5W Functions Monitor Current Readings, View Graphs...
Page 156: Options
Options AC adaptor (for RTR-5W) AD-0605 AC adaptor AC 100 to 120V Cable Length : 74in (1.85 m) Wall Attachment Unit (for RTR-5W) TR-5WK1 Wall Attachment Double-sided Adhesive Tape x 1 Materials : Polycarbonate...
Page 157 Temperature Sensors (For TR-52/RTR-52) unit: millimeters TR-5106 Fluoropolymer Coated Sensor Cable Length : 24in (0.6 m) Thermal Time Approx. 15 Sec. (in air) Constant : Approx. 2 Sec. (in agitated water) TR-5101 Fluoropolymer Coated Sensor Cable Length : 1.8in (45 mm) Thermal Time Approx.
Page 158 Temp / Humidity Sensor (For RTR-53) unit: millimeters TR-3310 Temp / Humidity Sensor Cable Length :40in (1 m) Materials : ① Temperature/Humidity sensor 　② Polypropylene resin 　③ Vinyl Coated Electrical Wire Possible Humidity Measurement Range : 10 to 95％ RH PossibleTemperature Measurement Range: 0 to 50ºC Sensor Temperature Durability :...
Page 159 Sensor Adaptor (For RTR-52Pt) unit: millimeters RTR-05P1　 Cable Length : 40in (1.0 m) Operational -25 to 60ºC Temperature : ※ Not Waterproof. Materials : ① Vinyl Chloride　② Vinyl Coated Electrical Wire Sensor Extension Cables (For RTR-52/RVR-52A) unit: millimeters TR-2C30 Sensor Extension Cable Cable Length : 120in (3.0 m) Operational...
Page 160 Power (For RTR-5/RVR-5) unit: millimeters RTR-05A1 External Power Adaptor Voltage Input: DC6V Back-up Power: Ni-MH Battery (In case of power loss) Back-up Time: 4 days (*1) Charging Method: Trickle Charge Operating 0 to 60ºC Temperature: Waterproof Capacity: None Weight : about 37g (without AC Adaptor) Kit Contents: Attachment hook x 1...
Page 161 Power (For TR-5/RTR-5/RVR-5) unit: millimeters TR-00P1 Maintenance Set　 Contents: Rubber Packing x 1 (for back of main unit) Silica Gel Pack (drying agent) x 1 Double-sided Adhesive Tape x 1 (for fastening silica gel) Screws x 2 (extras for fastening back of main unit) TR-11P2 Low-Temperature Battery Set Contents: Lithium Battery x 1 (LS14250) Tube x 1...
Page 162 Wall Attachment (For TR-5/RTR-5/RVR-5) unit: millimeters TR-05K3 Wall Attachment Operating Temperature: -40ºC to 80ºC Contents: Double-sided Adhesive Tape x 1 Screws x 2 Compatible devices： RTR-5/RVR-52A/TR-5 NOTE: If a strong shock occurs to the unit in environments under -30ºC, cracking may occur. Materials : ①...
Page 163 Please stop by and see what we have to offer. Web Wing WL RTR-5W User's Manual Published by T&D Corporation (US / 9 th Edition)

T&D RTR-5W User Manual

Quick Links

Related Manuals for T&D RTR-5W

Summary of Contents for T&D RTR-5W

Table of Contents
